Summary of Contents for Athena BATHROOMS Fleet Vanity
- Page 1 Fleet Vanity Installation Instructions BEFORE INSTALLATION PLEASE CHECK THAT YOUR ATHENA VANITY IS UNDAMAGED May 2022...
- Page 2 IMPORTANT: The Fleet vanity must be screwed into a Solid fixing such as studs or nogs. Failure to do this may cause the drawers not to operate correctly or in the worst case scenario become detached from the wall.
- Page 3 Installing the Fleet Drawer Remove the Drawer from the Drawer Body 1. Open the drawer fully. On the underside of the drawer locate the tabs on each side, press the tabs while lifting the drawer and pulling towards the front at the same time. This will release the drawer from it’s runners.
- Page 4 Installing the Fleet Drawer continued 6. Return the Drawer box into the Drawer body. Ensure that the rear clips of the runners are engaged into the rear of the drawer box. Please refer to the last page of the instructions for detailed Drawer runner installation &...
- Page 5 Fitting the Benchtop & Basin 7. To the corners of the Fleet Frame apply a pea sized amount of Silicone sealant. 8. Return the bench top to its final resting position and gently push down into the sealant. 9. To prevent any accidental water ingress apply a small bead of sealant around the underside of the benchtop and to the wall.
- Page 6 Removing the Drawer 1. Open the drawer fully. 2. On the underside of the Drawer locate the tabs on each side and press the tabs while lifting the Drawer and pulling towards the front at the same time. This will release the Drawer from it’s runners. Press Tab Installing the Drawer 1.
- Page 7 Adjusting Drawer Front Vertically ( +/- 2.0mm) The Drawer front is secured to the Drawer box by the mecha- nism and screws on the underside (refer images). The screws are temporarily held in by tape to allow adjustment of the Drawer front during installation. Once final adjustment is achieved, tighten up these screws.
- Page 8 Ph 09 443 9551 info@athena.co.nz | athena.co.nz May 2022...
