S6 Microsonde
User Guide
Introduction
The S6 Microsonde is a small diameter 6.4mm (0.25") battery
powered sonde transmitting on 33kHz and is compatible with a
wide range of Radiodetection locators. With its small diameter,
the S6 Microsonde is particularly useful in small diameter ducts
where it can be used to trace the path of the duct and in the
precise location of blockages or collapses.
The S6 Microsonde can be 'blown' or attached to a cable before
jetting it into the duct and may also be connected to a traditional
push rod and inserted into the duct or pipe. The route of the duct
can be traced using a Radiodetection locator and the precise
location and depth of a blockage can be detected.
Radiodetection supply a comprehensive range of sondes, some
locatable to depths of up to 15m (49') and with diameters ranging
from 6.4mm (0.25") to 64mm (2.52"), to suit a wide variety of
applications.
For more information on the full range of Radiodetection sondes,
go to www.radiodetection.com
Advertisement
Table of Contents
Related Manuals for SPX Radiodetection S6 Microsonde
Summary of Contents for SPX Radiodetection S6 Microsonde
- Page 1 S6 Microsonde User Guide Introduction The S6 Microsonde is a small diameter 6.4mm (0.25") battery powered sonde transmitting on 33kHz and is compatible with a wide range of Radiodetection locators. With its small diameter, the S6 Microsonde is particularly useful in small diameter ducts where it can be used to trace the path of the duct and in the precise location of blockages or collapses.
- Page 2 Using the S6 Microsonde The S6 Microsonde kit includes the following: Transmitter unit. Mounting connector containing battery compartment with M5 female thread. CR425 Lithium Ion battery. User guide. Operating the S6 Microsonde The Lithium Ion battery provides approximately 10 hours’ usage although battery life may be shorter in very cold conditions.
- Page 3 Jetting the S6 Microsonde without cable When jetting the sonde without the use of a cable, it is recommended to use the sonde within a protective tube when blowing through a duct to limit possible damage to the sonde – particularly if a blockage is encountered.
- Page 4 Tel: +44 (0) 117 976 7776 rd.sales.uk@spx.com www.radiodetection.com Copyright © 2022 Radiodetection Ltd. All rights reserved. Radiodetection is a subsidiary of SPX Corporation. Radiodetection is a trademark of Radiodetection Ltd. Due to a policy of continued development, we reserve the right to alter or amend any published specification without notice.
