Page 1 User manual v1.0...
Page 2: Table Of Contents
Safety instructions and warnings ………….…………….1 Overview …………………………………………………2 2.1. Inside the box ………………………………………………2-3 2.2. Specification ..……………………………………………….4 2.3. Product overview Getting started ……………………………5 3.1. Charging and powering monitor unit ……………………………………………6 3.2. Powering camera unit Operation – General mode ………………………………………………7 4.1. OSD icons …………… …………….…………………….………………….8 4.2.
Page 3: Safety Instructions And Warnings
Please read and follow all instructions and warnings in this user manual before using the product. Strangulation Hazard - Keep the adapter cord out of the reach ◼ of children. Never place the camera or cord within 3 feet of a crib or playpen.
Page 4: Inside The Box
2.1. Inside the box Thanks for purchasing aidios M1 wireless monitoring system. It contains below components : Monitor unit x 1 Camera unit with stand x 1 Rechargeable Lithium battery x 1 A/C adapters x 2 Mounting screw x 1...
Page 5 Monitor unit Display 4.3” color LCD at 480x272 Audio Built-in speaker and microphone Battery 1800mAh Lithium rechargeable Duration (screen on) ~10 hours Duration (VOX on) ~18 hours Operating voltage Camera unit Picture sensor 1/5” Color CMOS, 640x480 Optical lens F2.4, EFL 2.5mm, FOV 70∘ Night vision 8 x 940nm IR LEDs Light sensor...
Page 6: Product Overview
2.3. Product Overview...
Page 7: Charging And Powering Monitor Unit
3.1. Charging and powering monitor unit Loosen the screw and open battery door. Plug in the battery to pic. 1. the battery socket as shown in Close the battery door and tighten the screw. Plug the power adapter into an electrical outlet. Insert the pic.
Page 8: Powering Camera Unit
3.2. Powering camera unit Plug the power adapter into an electrical outlet. Insert the pic. 3 3.5mm plug to the power jack as shown in . Slide the power switch to 'ON' position to turn on the camera unit. Power LED indicator emits blue light when camera unit is turned on.
Page 9: Osd Icons
4.1. OSD icons Camera icons : Standard camera unit Camera unit at zoom mode Camera unit with pan tilt docking (*) Temperature reading icon will be displayed only when pan tilt docking is installed.
Page 10: Control Keys
4.2. Control keys Power button Press and hold : Power on/off Short press : video off mode (audio only) (*) Pan tilt mode only available when pan tilt docking is installed.
Page 11: Video Category
To enter menu mode, press ‘Enter’ key once. To leave menu mode, press ‘Exit’ key once. In menu mode, press arrow keys to navigate and select different options. Note : Some functions require pressing ‘Enter’ key to perform the action, which will be shown in function description column.
Page 12: Audio Category
5.2. Audio category Camera# volume Adjust sound output of registered camera (for 2 way talk, lullaby and nature sound) Low battery alert Toggle low battery alert on/off (2 beeps) Out of range alert Toggle out of range alert on/off (1 beep) Auto mute Toggle auto mute on/off (3 sensitivity levels) Toggle VOX on/off (3 sensitivity levels)
Page 13: Vox
5.2.2. VOX Alike auto mute function, the camera unit starts to detect noise level when VOX is enabled. It turns off both video and audio completely after a 10 seconds of continuous silence. Any noise detected afterwards will trigger both systems back on, and repeat the noise detection. Sensitivity setting is the same as auto mute function mentioned in 5.2.1.
Page 14: Add A Camera Unit
5.3.1 Add a camera 1. Select an ID for your new camera and move the cursor to this camera 2. Press left/right arrow key and select 'Pair' option. 3. Press 'Enter' key to perform pairing process. 4. Press and hold the 'Pair' button at the back of camera unit for 1 second. The power LED of camera unit will blink to indicate pairing mode.
Page 15: Picture In Picture (Pip)
5.3.3 Picture in picture (PiP) Picture in picture function allows viewing 2 camera units simultaneously. The video image of primary screen will be displayed at normal size. The video image of secondary screen will be reduced to 1/3 of its original size and displayed at lower right corner of screen.
Page 16: Troubleshooting And Tips
Problem Solution Product does not 1. Check the power adapter is properly switch on connected to the device and wall outlets. 2. Swap the power adapter to check if the problem is caused by a defected adapter. 3. Double check if the monitor unit and camera unit is powered on.
Page 17 Connection issues 3. Place the monitor and camera units (continued) closer, if possible. 4. Avoid large metallic objects in close proximity to the monitor or camera unit. 5. Place the monitor or camera unit at least 3 feet from any 2.4GHz device, such as WiFi router, smartphone or microwave oven.
Page 18 Annoying beep There are 2 types of beep alerts, low alerts battery and out of range. System delivers one beep every 10 seconds if the monitor cannot communicate with camera unit. System delivers two beeps every 10 seconds if the battery capacity is low. Both alerts can be enabled or disabled in user menu.
Page 19: Warranty Information
We warrant to the original user that the product is free from material and workmanship defects for a period of one (1) year from the date of original purchase. If this monitoring system fails to function properly when used as directed under normal condition within the one year period, we will either repair or replace the product, at our discretion, free of charge.
Page 20: Fcc Statement
WARNING : Modifications not authorized by the manufacturer may void users authority to operate this device. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 21: Declaration Of Conformity / Others
Declaration of Conformity : Hereby aidios Ltd., declares that the aidios M1 and the series is in compliance with essential requirements and other relevant provision of Red Directive 2014/53/EU. The product had designed, tested and manufactured according the European Red Directive 2014/53/EU.
