SUPMOGO Fitness Wearable Belt User Manual

Underweight
U S E R
M A N U A L
Before using the product, please read the manual carefully.
Save the manual
1. Introduction
1.1 Working Principle
The SUPMOGO Fitness Wearable Belt delivers "passive" training to
the muscles of the abdominal region through the application of EMS
(electronic muscle stimulation). This is a technology that stimulates
muscle contractions by mimicking the signals that the central
nervous system naturally sends to the neuron of the cells.
1.2 What's Included?
The SUPMOGO Fitness Wearable Belt Includes the following
components:
The SUPMOGO Fitness Wearable Belt, The SUPMOGO Belt
Extension, The Smart Battery with Bluetooth Technology, The
Charging Cable, The SUPMOGO Spray Bottle, The SUPMOGO Light
Cover, The SUPMOGO Wash Bag, as well as access to the
SUPMOGO App.
2. Instruction
[1] Preparation
2.1.1 Charge
Connect the Type-C end of the USB cable provided to the Type-C
USB port on The Smart Battery. Connect the other end to a charging
box or a standard USB-A port. When charging starts, the indicator
light on The Smart Battery turns red. The light turns green when the
battery is fully charged.
Attention:
1. The Smart Battery operates off of a built-in rechearchable battery.
Please charge it before your rst time use.
2. Please use the USB cable provided to charge The Smart Battery.
3. It is recommended to charge The Smart Battery at room
temperature (extreme weather conditions may reduce the capacity).
4. It is recommended to charge The Smart Battery with a 5V 1A
charger. It takes about 1 hour for it to be fully charged.
5. The device can be used for about 5-10 hours once fully charged
(with an intensity level of 35 or lower).
*The battery life varies at different intensity levels and different
temperatures*
2.1.2 Download The SUPMOGO APP
IOS: Download SUPMOGO App from the App Store.
Android: Download SUPMOGO App from Google Play.
2.1.3 Fasten The SUPMOGO Fitness Wearable Belt
I. Before wearing the belt, spray the water evenly on the surface of
the conductive fabric to ensure that it is suf ciently moist for
successful impulse signal transmission.
II. Wrap the belt around the waist tightly to ensure that the
conductive fabric fully touches the skin.
Attention:
The conductive fabric transmits impulse signals ONLY when the skin
surface is suf ciently moist (skin is mildly sweating or the conductive
fabric is saturated). If the surface of the skin is not producing sweat,
reapply water every 30 minutes to 1 hour to continue the workout.
If you feel a slight discomfort or a prickly feeling, reapply water
accordingly.
2.1.4 Install The Smart Battery
Match the 2 Push-buttons on the back of The Smart Battery with the
2 Push-button bases on the front side of the belt. Make sure the
Push-buttons are locked into the bases completely (no distinction of
the left or right).
2.2.1 Turn on The Smart Battery
After attaching The Smart Battery to the SUPMOGO Fitness
Wearable Belt, press the power switch of The Smart Battery (long
press for 2 seconds) to turn on the device. The Smart Battery should
have a blue ashing indicator shown on the front side.
2.2.2 Connect The Smart Battery
Open the SUPMOGO App. In the App, click "Pair Device".
Once the Bluetooth device list pop up appears, choose your
device and click the "Pair" button. Once the Smart Battery
LED Indicator starts ashing green, you are connected.
Attention:
Please ensure the Bluetooth settings on your smartphone are set to
discoverable. A message will be prompted stating that our app is
requesting to turn on Bluetooth if the Bluetooth is off.
2.2.3 Exercise with The SUPMOGO Fitness Wearable Belt
1) Start the exercise
On the operation interface, click 'Quick Start' to begin your exercise.
2) Adjust the intensity level
a. On the operation interface, click the '+' button to increase the
intensity level and the '-' button to decrease the intensity level.
b. The initial intensity level is set at 0. The intensity level can be
adjusted step by step during the exercise.
3) Adjust the pulse and rest levels
a. On the operation interface, click the '+' button to increase the level
and the '-' button to decrease the level. The pulse controls the
contraction time and the rest controls the time between contractions.
2.2.4 End the Exercise
1) Click the OFF button on the app.
2) Turn off The Smart Battery (hold the power switch button on The
Smart Battery for 2 seconds).
3) Take The Smart Battery off of the belt and exit the app.
4) Take off the SUPMOGO Fitness Wearable Belt.
