HOOTBOOTH ILLUMIN8+ Hardware Setup Manual

Hide thumbs

Advertisement

Table of Contents

HootBooth® ILLUMIN8+
Hardware Setup Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ILLUMIN8+ and is the answer not in the manual?

Questions and answers

Related Manuals for HOOTBOOTH ILLUMIN8+

Summary of Contents for HOOTBOOTH ILLUMIN8+

  • Page 1 HootBooth® ILLUMIN8+ Hardware Setup Guide...
  • Page 2 1. Attach lower pedestal piece to base plate using two tri-side thumb screws. HootBooth ® ILLUMIN8+ Assembly Guide...
  • Page 3 2. Attach upper pedestal piece to lower pedestal piece using 2 thumb screws. HootBooth ® ILLUMIN8+ Assembly Guide...
  • Page 4 3. Remove four thumb screws from back cover of top piece. HootBooth ® ILLUMIN8+ Assembly Guide...
  • Page 5 Plug iPad charger into available outlet inside unit. Plug cable provided with iPad into iPad. Bundle wiring neatly. Replace wing nuts and back cover thumb screws. **See note at bottom regarding potential need for adapter** HootBooth ® ILLUMIN8+ Assembly Guide...
  • Page 6 5. Mount half-circle bracket to the top of the unit using single thumb screw. HootBooth ® ILLUMIN8+ Assembly Guide...
  • Page 7 6. Mount top piece to half-circle bracket as shown below using two thumb screws. Ensure the black plastic spacers are installed as shown. 7. Plug power cable into wall outlet or extension cord and test that iPad is charging and ring light is working. HootBooth ® ILLUMIN8+ Assembly Guide...
  • Page 8 The older 11” iPad models used a lightning port. The Illumin8+ model you have uses a USB-C receptacle. If you find the cable provided with your iPad does not fit into the receptacle, you just need to purchase a USB-C to USB-A adapter such as this, also pictured below: HootBooth ® ILLUMIN8+ Assembly Guide...
