Summary of Contents for BTSX BIT-MSE-8K-309HD

Page 1: Table Of Contents
Shenzhen Bitvisus technology limited. Video News Co., Ltd Catalog 1.product description ..............2 1.1. Product Features ..............2 1.2. Application scenarios............3 3. Operation Instructions.............5 8K Multi screen expansion 3.1 . Device panel description..........5 3.2 . Classic connection case ............ 7 3.
Page 2: Product Description
Shenzhen Bitvisus technology limited. Video News Co., Ltd 1.product description 1.1. Product Features 1. BIT-MSE-8K-309HD is an industrial-grade high-performance product specially developed for the fusion of multi-desktop operation and multi-channel projection. It adopts HDMI/DP input interface and HDMI output interface.
Page 3: Application Scenarios
LCD/LED multi-screens, etc. 2. Product Specifications product name BIT-MSE-8K-309HD Input interface maximum video pixel 600MHz _ frequency Output interface maximum video pixel 165MHz _ frequency Input interface type 3 HDMI ports, 3 DP ports 第...
Page 4 Shenzhen Bitvisus technology limited. Video News Co., Ltd Output interface type 10 HDMI outputs 5x1920x1200 @ 60Hz 5x1920x108 5 screens support 0 @ 60Hz _ _ _ typical resolution 5x12 8 0x8 0 0 @ 60Hz 5x10 24x768 @ 60Hz _ 7x1920x1200 @ 60Hz 7x1920x108 7 screens support 0 @ 60Hz _ _ _...
Page 5: Operation Instructions
Shenzhen Bitvisus technology limited. Video News Co., Ltd 3. Operation Instructions 3.1 . Device panel description A: Power interface, connect to 12V@2A power supply. The LED light (power) next to the interface is the power indicator. When the device is powered normally, the LED light is always B: 10 HDMI output interfaces, used to connect display devices such as monitors, TVs or monitors.
Page 6 Shenzhen Bitvisus technology limited. Video News Co., Ltd output or other devices on the PC host. I: Audio output interface, used for audio output devices, headphone audio, etc. J: Power switch. 第 6 页共 13 页...
Page 7: Classic Connection Case
Shenzhen Bitvisus technology limited. Video News Co., Ltd 3.2 . Classic connection case 1) The output of the computer graphics card is connected to the input of the multi-screen treasure. 2) The output of the multi-screen treasure is connected to the display device, and the serial number of the output port of the multi-screen treasure is connected to the corresponding display screen.
Page 8: Custom Resolution
Shenzhen Bitvisus technology limited. Video News Co., Ltd 3. 3. Custom resolution Step 1: Right-click on the desktop and select "NVIDIA Control Panel" in the pop-up box. Step 2: Select "Change Resolution", select the multi-screen device to be changed, and then click "Customize". Step 3: Select "Create Custom Resolution".
Page 9: Rotating The Display
Shenzhen Bitvisus technology limited. Video News Co., Ltd 3.4 . Rotating the display Right-click on the computer desktop and select "NVIDIA Control Panel" 4.common problem 4.1 , Multi-screen treasure equipment problem 4.1.1 Multi-screen red light problem 1. Check the power cord, the supplied 12V power cord must be used for power supply.
Page 10 Shenzhen Bitvisus technology limited. Video News Co., Ltd 1. The input signal lamp is damaged, or other faults (EDID chip damage, etc.). 2. The input signal light is damaged, or other faults (computer graphics card problem, device resolution problem, secondary device problem, and signal line problem, etc.).
Page 11: Computer Graphics Card Problem
Shenzhen Bitvisus technology limited. Video News Co., Ltd 4.2 , computer graphics card problem 1. Check whether the graphics card needs additional power supply. Multi-output graphics cards with multiple output ports generally require additional power supply. Whether there is an output port switch control, please refer to the instruction manual of the corresponding model graphics card.
Page 12: Display Device Problem
Shenzhen Bitvisus technology limited. Video News Co., Ltd 4.3 . Display device problem 1. Whether the display device supports the output resolution, you can directly connect the computer graphics card to the device to test this resolution 2. Display whether the power supply of the device is stable, turn on the signal receiving function (boot, search signal function, etc.) 3.
Page 13: Problem Solving
Shenzhen Bitvisus technology limited. Video News Co., Ltd 4.4 , problem solving _ Preconditions problem Solution phenome output image Set the computer properties, set the resolution blue desktop properties to "tile" correct Integrated no image Change the discrete graphics card, Graphics output or contact a technician...
