Saniclass Adema Lonato Installation Instructions

Ip44 illuminated mirrors

Before installing this product pay special attention to these instructions. It is recommended

that this product is installed by a qualified electrician and current building regulations.

These products can safely be fitted into Zone 2. See lighting regulations diagram.

Prior to commencing work isolate the power supply cable at the fuse box.

Check that there are no other concealed cables or pipe work in the intended installation area

(check the entire area).

The mirror is mounted on the wall by means of two fixing screws.

Make sure that it is at the correct height and level. Using a suitable marker through the fixing

holes mark the position of the holes on the wall.

Using the correct size drill bit for the wall fixing (please note that for certain wall types i.e.

plasterboard walls, the wall fixings supplied are not recommended) drill holes in the marked

locations. Place the rawl plugs into the holes. Feed the supply through the central rubber

grommet, position the back plate and secure using the correct fixings (the rubber washers

provided must be used to ensure no water can penetrate into the fitting).

Connnect the supply cable to the connector block as shown in the wiring diagram. Ensure the

conductors are fully inserted into the terminals and no loose wire strands are protruding. fully

tighten the screws on the terminals making sure that the screw clamps onto the conductor and

not the insulation.

Fix the mirror to the wall.

Ensure that the correct type and wattage bulb are always used. (see Luminaire for details).

Shelf fixing (selected models only).

To fix glass shelf to mirror attach the metal support arms to the bottom of the mirror frame using

the screws provided. (the rubber washer supplied must be used to ensure that IP44 is

maintained). Place the glass shelf and secure with the screws located underneath the metal

support arm.

Cleaning Instructions

In order to maintain the quality finish of this product please do not use any abrasives or solvents

when cleaning this product. Use only a damp cloth for cleaning this product.

Do not allow water to stand on any part of the mirror.

Please clean any spillage that may affect the quality of the finish as described above.

Table of Contents

Do you have a question about the Adema Lonato and is the answer not in the manual?

Page 1 Before installing this product pay special attention to these instructions. It is recommended that this product is installed by a qualified electrician and current building regulations. These products can safely be fitted into Zone 2. See lighting regulations diagram. Prior to commencing work isolate the power supply cable at the fuse box. Check that there are no other concealed cables or pipe work in the intended installation area (check the entire area).
Page 2 Packing information & installation Package content: LED Backlit Mirror Screws Manual Attention: installation and connection to electric wiring must be done by a professional electrician in compliance with local requirements for electrical installations. Never modify the construction or add any parts which are not offered as spare parts or accessories by the manufacturer of the luminaire.
Page 3 Installation Steps...
Page 4 Electrical Wiring & Warranty Warranty Once received carefully inspect your mirror and packaging. Mirrors come with a 2 year warranty subject to company policy. Contact your nearest distributor in case of any issue. Special Care Care Should be exercised when cleaning this product. Although its finish is extremely durable, it can be damaged by harsh abrasives and cleaning pads.
