Dr. Storage F1 Manual

Dry cabinet
Hide thumbs
Table of Contents

Advertisement

Quick Links

F1/X2B/A1B/T40W/T60M
F1/X2B/A1B/T40W/T60M
Dry Cabinet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dr. Storage F1

  • Page 1 F1/X2B/A1B/T40W/T60M F1/X2B/A1B/T40W/T60M Dry Cabinet...

  • Page 2: Table Of Contents

    Contents General specifications -F1 General specifications -X2B General specifications -A1B General specifications -T40W General specifications -T60M Installation Introduction of control Panel Alert Setting for Humidity(all models) Alert Setting for Temperature (all models) How to set Humidity(A1B Only) How to set Temperature (T40W/T60M Only)

  • Page 3: General Specifications -F1

    General specifications ■F1 RS232 Port Control Panel Antistatic Glass Shelf Handle Adjustable Level bolt Antistatic 3” Wheel Front Right Power Cable Power Box Power Wiring Diagram Model: F1-1200-6 Extension Cable Dehumidifier unit Power Box Dehumidifier unit Back...

  • Page 4: General Specifications -X2B

    General specifications ■X2B RS232 Port Control Panel Antistatic Glass Shelf Handle Adjustable Level bolt Antistatic 3” Wheel Front Right Power Cable Power Box Power Wiring Diagram Model: X2B-1200-6 Extension Cable Dehumidifier unit Power Box Dehumidifier unit Back...

  • Page 5: General Specifications -A1B

    General specifications ■A1B RS232 Port Control Panel Antistatic Glass Shelf Handle Adjustable Level bolt Antistatic 3” Wheel Front Right Power Cable Power Box Power Extension Cable Wiring Diagram Model: A1U/A1B-1200-6 Signal Cable Dehumidifier unit Power Box Dehumidifier unit Back...

  • Page 6: General Specifications -T40W

    General specifications ■T40W RS232 Port Back Cover Control Panel Memo Card Compression Shelf Handle Antistatic Glass Adjustable Level Screw Antistatic 3” Wheel Front Right Power Cable Power Heater Switch Power Box Dehumidifier Heater Wiring Diagram Overheat Protector Please set the knob at 50℃.

  • Page 7: General Specifications -T60M

    General specifications ■T60M RS232 Port Control Panel Grid Shelf Memo Card Compression Handle Antistatic Glass Antistatic 3” Wheel Adjustable Level bolt Front Right Power Cable Power Overheat Protector Heater Power Sw i tch Please set the knob P4-1 P1-1 at 70℃. Wiring Diagram Model: T60M-1200-6 P4-1...

  • Page 8: Installation

    Adjust the feet to balance the cabinet. F1/X2B/A1B T40W/T60M STEP2 Install shelves: 1.Moveable column: the moveable column can be taken out for installing the shelves. available models( F1/X2B/A1B-315/575/1200-6 ) fasten knob 2.Two methods for putting clips and shelves: Shelves removable Shelves fixed...
  • Page 9 Installation 3.The installation of Stopper: this stopper will avoid the object to drop down from the gap between the shelf and wall of cabinet.available models( F1/X2B/A1B-157/315/575/200/400 1600/1200-6 ) Stopper Shelf STEP3 Connect modules:connect all modules according to the Wiring Diagram which is affixed at the back of cabinet.
  • Page 10 Installation ■Bin set up(available for F1/X2B/A1B) 1.Insert the tenons at the bottom of bin into the slots on window frame. 2.Bend both sides of bin then insert the tenons into the slots on window frame . The opera�on mode of interior lights:(available for T40W/T60M) ■...

  • Page 11: Introduction Of Control Panel

    Introduction of control Panel Description: 1. SET Button 7. UP Button 2. Temperature Display 8. Power Button of Display 3. Humidity Display 9. Flash Alarm Lamp 4. Select Button 5. Calibration Expiration Button 6. DOWN Button Calibration Reminding function The drift effect of sensor might influence the accuracy. In order to help complying with the regulation of ISO.

  • Page 12: Alert Setting For Humidity(All Models)

    Alert Setting for Humidity(all models) ■ Set upper limit of humidity alarm(AHu) Example [ Alert ] Set AHu as 60%RH. Alert is activated when the relative humidity is higher than 60%RH. STEP1 Press and hold ▲, then press SET. STEP2 Press ⊙ to select from H→AHu. Choose AHu. STEP3 Press ▲...
  • Page 13 Alert Setting for Humidity(all models) ■Time delay setting of humidity Flash alarm(AHF) When the relative humidity is higher than 60%RH, flash will be activated from Hb to Hc. AHu=60 AHF=3 min Flash Time delay time Set AHF Step 1 Press and hold ▲, then press SET. Step 2 Press ⊙...
  • Page 14 Alert Setting for Humidity(all models) ■ Time delay setting of humidity buzzer alarm(AHb) When the relative humidity is higher than 60%RH, buzz will be activated from Hb to Hc. AHu=60 AHb=60 min buzzer Time delay time Set AHb Step 1 Press and hold ▲, then press SET. Step 2 Press ⊙...

  • Page 15: Alert Setting For Temperature (All Models)

    Alert Setting for Temperature (all models) ■ Set upper limit of temperature alarm (Atu) Example [ Alert ] ℃ Set Atu as 30 ℃ . Alert is activated when the temperature is higher than 30 ℃ . STEP1 Press and hold ▼, then press SET. STEP2 Press ⊙...
  • Page 16 Alert Setting for Temperature (all models) ■Time delay setting of temperature flash alarm(AtF) When the relative temperature is higher than 30 ℃ ℃ flash will be activated from Hb to Hc. Atu=30 AtF=3 min Flash Time delay time Set AtF Step 1 Press and hold ▼, then press SET.
  • Page 17 Alert Setting for Temperature (all models) ■Time delay setting of temperature buzzer alarm(Atb) When the relative temperature is higher than 30 ℃ ℃ buzzer will be activated from Hb to Hc. Atu=30 Atb=60 min buzzer Time delay time Set Atb Step 1 Press and hold ▼, then press SET.

  • Page 18: How To Set Humidity(A1B Only)

    How to set the relative humidity(A1B Only) ■ Relative humidity setting: STEP1 Press and hold ▲, then press SET. (The humidity display will show H, while the temperature display will flash the current humidity setting.) STEP2 Press ▲ or ▼ to reach the required humidity level . (setting range: 0~99%RH) STEP3 Press SET to store the setting.

  • Page 19: How To Set Temperature (T40W/T60M Only)

    How to set temperature (T40W/T60M Only) STEP1 Press and hold ▼, then press SET. (The humidity display will show t, while the temperature display will flash the current temperature setting.) STEP2 Press ▲ or ▼ to reach the required temperature level of 60℃. (setting range: 0~60℃) STEP3 Press SET to store the setting.

  • Page 20: How To Use Software Humidity Manager V3

    How to use software Humidity Manager V3 ■Installation STEP1 To install USB-RS232 driver by double clicking icon of “PL-2303 Driver Installer”. STEP2 To install Huminity Manager by double clicking icon of “setup”. STEP3 Restart the PC.
  • Page 21 How to use software Humidity Manager V3 ■General information Title Bar Data Acquisition Function Bar Termination of data acquisition Tool Bar Tracking Temperature Scale Humidity Scale Display Mode (℃/℉) Temperature Curve Reduce Humidity Curve Enlarge Upper Limit Bar Lower Limit Bar Shift Left Time Line Shift Right...
  • Page 22 How to use software Humidity Manager V3 ■Operation STEP1 Connect USB-RS232 cable from the dry cabinet to PC. Control Panel STEP2 Decide on the “Interval” and press “ ”.
  • Page 23 How to use software Humidity Manager V3 STEP3“Is the time interval correct?” will appear. Press “Yes” to confirm the settings. Enter a file name and press “Save”. The software begins to capture the data and the procedure is completed. ■Floor Life Counter (V3) Press “...

  • Page 24: Notes

    Notes ■For Proper Installation 1.The dry cabinet is operated under the condition below 30℃, 60%RH. 2.Please place the dry cabinet on a leveled ground. 3.Please place the cabinet away from direct outlet of ventilation. Because the strong wind pressure will lead to the penetration of moisture into the dry cabinet.

  • Page 25: Warranty

    Warranty 1.If the dry cabinet is abnormal, please continually record the relative humidity graph for 24 hours then send it to service@dr-storage.com. 2.If we determine the malfunction of product, please carefully wrap and deliver the parts back to us for maintenance. 3.Please do not attempt to open or repair the dehumidifier unit by yourself.
  • Page 26 For best result, please read this manual before using the product. M180515...

This manual is also suitable for:

X2bA1bT40wT60m
