Summary of Contents for Kielder KWT-002
- Page 1 18V CORDLESS IMPACT WRENCH TYPE18 ORIGINAL INSTRUCTION MANUAL For use with all variants of KWT-002 & KWT-012 Cordless Impact Wrench K I E L D E R 1 8 V B AT T E RY S Y S T E M www.kielder.co...
- Page 2 KWT-002-012-IMB22 Kielder WT Ltd...
- Page 3 Tel: 0114 242 3794 EN 60745-2-2:2010 EN 55014-1:2006+A1:2009+A2:2011 Email: tools@kielder.co EN 55014-2:1997+A1:2001+A2:2008 All documentation is held in KWT-002 Technical Intended Use File and is available, on request for review. The tool is intended for the fastening and Authorised Signatory: unfastening of threaded bolts and nuts.
- Page 4 • If devices are provided for the connection rate for which they were intended. of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. KWT-002-012-IMB22 Kielder WT Ltd...
- Page 5 Service are caused by poorly maintained power Have your power tool serviced or repaired tools. by Kielder or a qualified technician using • Keep cutting tools sharp and clean. only identical replacement parts. This will Properly maintained cutting tools with...
- Page 6 • Secure the workpiece. A workpiece is instructions: held more securely in a vice than by hand. KWT-002-012-IMB22 Kielder WT Ltd...
- Page 7 • Do not use other than the Kielder battery packs that are designed for use with this rechargeable tool. Li-Ion • Kielder is not responsible for any damage or...
- Page 8 Battery Charge Level Indicator Square Drive Shoulder (10) Battery Release Button Socket Retainer (11) Charger Forward / Reverse / Lock Selector (12) Battery Insert Slide Trigger (13) Charging Indicator Hand Grip (14) Torque Setting - KWT-012 Only Belt Clip KWT-002-012-IMB22 Kielder WT Ltd...
- Page 9 Conforms to CE Wear Hearing Protection standard Revolutions Per Minute Do not burn or Wear Safety Glasses incinerate Electrical Capacity Wear Vibration Absorbing Maximum safe ambient Class II construction Gloves temperature for battery (double insulated) MAX 45ºC Kielder WT Ltd KWT-002-012-IMB22...
- Page 10 Slide the battery pack until it locks into against the square drive shoulder (C) position with an audible “CLICK”. To further secure the socket, your Kielder Impact Wrench is equipped with a ball bearing style retaining system. This allows any suitably designed sockets to be...
- Page 11 • When in forward (clockwise) mode the last setting used (Hi or Lo) will remain programmed. Please Note : In reverse (anti-clockwise) the tool will always be in Hi torque mode. Lo torque mode cannot be selected. Kielder WT Ltd KWT-002-012-IMB22...
- Page 12 Charge Red light illuminated = No Charge If the battery is of low charge, it should be charged before further use. The battery level indicator may be used with battery connected or disconnected to the tool. KWT-002-012-IMB22 Kielder WT Ltd...
- Page 13 • Do not store the battery pack in locations where the temperature may reach or exceed 45°C. • Do not incinerate the battery pack even if it is severely damaged or is completely worn out. The battery pack can explode in a fire. Kielder WT Ltd KWT-002-012-IMB22...
- Page 14 If any dirt is found on the pack to cool down before recharging. This terminals clean the terminals before charging the battery pack. will allow the battery to be recharged to its full capacity. KWT-002-012-IMB22 Kielder WT Ltd...
- Page 15 • Once charging is complete slide the original, have the charger tested by a battery out of the charger, disconnect the qualified person. charger from power supply and store. Kielder WT Ltd KWT-002-012-IMB22...
- Page 16 CHART fouled in some way. 1 & CHART 2, with the torque curve CHART 1: KWT-002 MODEL flattening between 10 and around 20 seconds depending on application. Torque (Nm) Threaded Fastening Standard Tensile •...
- Page 17 • If the inside of the tool or battery pack is exposed to water, drain and allow to dry thoroughly as soon as possible. If you experience any problems when operating the tool, contact Kielder WT. Kielder WT Ltd KWT-002-012-IMB22...
- Page 18 • Use of the machine in the UK only, overseas Why is Registration a Requirement? users should contact the official importer or For Kielder to be able to fully support & retailer for that country. service a product warranty over a 3 year...
- Page 19 Kielder WT Ltd KWT-002-012-IMB22...
- Page 20 KWT-002-012-IMD18 Kielder WT Ltd Kielder K I E L D E R W O R K S T E A M Kielder WT Ltd Sheffield, UK T: +44 (0)114 242 3794 E: tools@kielder.co W: http://www.kielder.co Kielder Tools Registered in England & Wales: 09426163...
