MECHANICAL TRANSPLANTER 1000 Operator's Manual

Table of Contents

Quick Links

Download this manual

Mechanical Transplanter Co.

Model 1000 and 1000B-3

Operators Manual

Mechanical Transplanter Co., LLC

1150 Central Avenue • Holland, MI 49423-5230

Phone: 616-396-8738 • Fax: 616-396-3619

website: www.mechanicaltransplanter.com

e-mail: mtc@mechanicaltransplanter.com

Made in USA

Table of Contents

Troubleshooting

Need help?

Do you have a question about the 1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for MECHANICAL TRANSPLANTER 1000

Page 1 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 2 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 3 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 4 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 5 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 6 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 7 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 8 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 9 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 10 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 11 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 12 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 13 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 14 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 15: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 16: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 17 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 18 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 19 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 20 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 21 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 22 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 23 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 24 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 25 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 26 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 27 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 28 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 29 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 30 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 31: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 32: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 33 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 34 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 35 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 36 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 37 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 38 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 39 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 40 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 41 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 42 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 43 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 44 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 45 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 46 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 47: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 48: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 49 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 50 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 51 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 52 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 53 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 54 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 55 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 56 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 57 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 58 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 59 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 60 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 61 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 62 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 63: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 64: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 65 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 66 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 67 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 68 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 69 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 70 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 71 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 72 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 73 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 74 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 75 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 76 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 77 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 78 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 79: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 80: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 81 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 82 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 83 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 84 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 85 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 86 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 87 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 88 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 89 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 90 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 91 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 92 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 93 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 94 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 95: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 96: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 97 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 98 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 99 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 100 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 101 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 102 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 103 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 104 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 105 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 106 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 107 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 108 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 109 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 110 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 111: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 112: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 113 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 114 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 115 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 116 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 117 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 118 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 119 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 120 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 121 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 122 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 123 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 124 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 125 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 126 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 127: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 128: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 129 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 130 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 131 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 132 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 133 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 134 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 135 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 136 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 137 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 138 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 139 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 140 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 141 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 142 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 143: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 144: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 145 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 146 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 147 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 148 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 149 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 150 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 151 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 152 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 153 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 154 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 155 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 156 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 157 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 158 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 159: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 160: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 161 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 162 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 163 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 164 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 165 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 166 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 167 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 168 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 169 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 170 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 171 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 172 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 173 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 174 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 175: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 176: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 177 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 178 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 179 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 180 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 181 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 182 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 183 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 184 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 185 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 186 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 187 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 188 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 189 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 190 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 191: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 192: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 193 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 194 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 195 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 196 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 197 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 198 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 199 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 200 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 201 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 202 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 203 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 204 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 205 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 206 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 207: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 208: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 209 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 210 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 211 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 212 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 213 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 214 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 215 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 216 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 217 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 218 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 219 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 220 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 221 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 222 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 223: Troubleshooting
Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 224: Safety Precautions
This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.
Page 225 Mechanical Transplanter Co. Model 1000 and 1000B-3 Operators Manual Mechanical Transplanter Co., LLC 1150 Central Avenue • Holland, MI 49423-5230 Phone: 616-396-8738 • Fax: 616-396-3619 website: www.mechanicaltransplanter.com e-mail: mtc@mechanicaltransplanter.com Made in USA...
Page 226 5-1/2” 4-1/2” 6-1/4” 6-1/2” 7-1/4” 8” 2-1/2” 3” 3-1/2” 3-3/4” 4-1/2” 3-3/4” 4-1/2” 5-1/4” 5-1/4” 6” 7” 7-1/2” 8-1/2” 2-1/2” 3” 3-1/2” 4-1/4” 4-3/4” 4” 5” 6” 5-1/2” 6-1/2” 7-1/2” 9” 10” Use for Model 1000 with disc mounted pockets...
Page 227 Assembly Instructions For Model 1000 Series Transplanters 2. Remove the following parts from the 1. Bolt on the Direct Drive Float direct drive wheel jackshaft: Clip pin, Wheel using the four 1/2 x 1-1/2 " drive chain coming from the wheel, bolts.
Page 228 4. Select the proper sprocket arrangement for the spacing needed between plants. Look on page 2 or the chart on the side of your transplanter for the correct arrangement. For spac- ings using 11 tooth sprockets, extra chain links may be needed to lengthen the drive chain. These links are wired to the lift chain by the drive wheel.
Page 229 Installation of Plant Stands It is very important to know what row width will be used before installing the plant stands on multi-row transplanters. Follow the chart below. 42" Row Spacing - All Wide Plant Boxes 41" to 36" Row Spacing - Narrow Plant Boxes Inside 35"...
Page 230 6. Install the plant boxes. These can be adjusted forward or backward for operator comfort. Assembling the L-Shaped Seat Braces 1. Assemble the L-shaped seat brace by the chain guard. The sea brace mounts on the inside of the frame. The U-bolt mounts from the outside of the transplanter frame under the chain guard.
Page 231 Mounting your Fiberglass or Cushion Seat •Fiberglass Seats• Fiberglass Seat - Turn your ﬁ berglass seat over and remove any covers over the threaded studs. Take your green ﬁ berglass seat bracket and mount it to the bottom of the seat with the side with the bend towards the front of the seat.
Page 232 Loose Pocket Assembly If your Model 1000 was shipped in a crate, a pocket must be put on the empty attachment link. The empty attachment link should be right at the top of the chain when the unit is shipped. If it is not, turn the drive wheel until the empty attachment link comes to the top.
Page 233 Instructions for Direct Drive Clamps The following instructions are for mounting the direct drive clamps to your Model 1000 unit. Al- though the pictures show the 2-1/2" clamps, use these instructions for any clamp style. They all mount the same way.
Page 234 3-point hitch will not go low enough. Correct height of toolbar is 14" to center. The Model 1000 unit can now be mounted to your 3-point hitch or toolbar. Following is a list of fasteners that you must use for various toolbars.
Page 235 Model 1000B-3 Barrel Mounting & 3-Point Hitch Instructions For B-3 Model, make sure the safety bar is properly installed! To mount this safety bar, you must remove the 7/16 x 1-1/4" bolt from on side of the direct drive wheel. 1.
Page 236 4. Bolt barrel hoops onto B-3 supports using 1/2 x 3" hex bolt with 1/2" lock nut. Note below: the hoops can be mounted in a forward or back position, depending on clearance that you need for the tractor fenders etc. Side view of B-3 mountings 5.
Page 237 A. Grease all ﬁ ttings before the start of each day. Grease ﬁ ttings are found: 1. On each packing wheel axle. 2. Upper pocket chain sprocket (Model 1000 only) 3. Direct drive tire hub (Direct Drive Units only) 4. On each nylon bushing on the pocket chain jackshaft.
Page 238 Example: At 20" row spacing, the #603 water cam should be adjusted nearly all the way up the slot. The #604 water adjustment must also be adjusted accordingly so a 1/2" remains on the 604 stroke. 4. Tilting the #603 water cam back towards the water trips on the pockets will create a longer stroke of water or more water before and after the plant.
Page 239 Important - Before attempting any of the following, make sure that the unit is running level or parallel to the ground. Do not run the front hitch or toolbar too far down or up. On all Model 1000 series units, make sure that the chains are loose on both sides of the arch bracket over the drive wheel.
Page 240 This limited warrantly does not apply to exterior ﬁ nishes, tires, chain links, bearings, or any other items sold by Mechanical Transplanter Co., but warranted by the original manufacturer except to the extent of their individual manufacturer's warranty.

This manual is also suitable for:

1000b-3

MECHANICAL TRANSPLANTER 1000 Operator's Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MECHANICAL TRANSPLANTER 1000

Summary of Contents for MECHANICAL TRANSPLANTER 1000

This manual is also suitable for:

Table of Contents
