Hitbox ARC160D Operation Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARC160D and is the answer not in the manual?

Questions and answers

Related Manuals for Hitbox ARC160D

Summary of Contents for Hitbox ARC160D

  • Page 3: Table Of Contents

    Z2A5 SC-A0 DIRECTORY 1. SAFETY-------------------------------------------------------------------------------------------------------------------3 2. SYMBOL EXPLANATION--------------------------------------------------------------------------------------------4 3. PRODUCT OVERVIEW-----------------------------------------------------------------------------------------------5 4. FUNCTION OVERVIEW---------------------------------------------------------------------------------------------- 5 5. PERFORMANCE CHARACTERISTICS------------------------------------------------------------------------- 5 6. ORDER INFORMATION----------------------------------------------------------------------------------------------6 7. TECHNICAL PARAMETERS----------------------------------------------------------------------------------------7 8. ELECTRICAL SCHEMATIC DIAGRAM--------------------------------------------------------------------------8 9. OPERATION CONTROL AND DESCRIPTION-----------------------------------------------------------------8 10.SYSTEM CHARACTERISTICS-------------------------------------------------------------------------------------9 11. INSTALLATION, DEBUGGING AND OPERATION---------------------------------------------------------10 11.1 Connection of switching box--------------------------------------------------------------------------------10 11.2 Installation----------------------------------------------------------------------------------------------------------10 11.3 Operation-----------------------------------------------------------------------------------------------------------11...

  • Page 4: Safety

    1. SAFETY Beware of electric shock!  Install grounding device according to application standard.  Do not touch live parts with naked skin, wet gloves or wet clothes.  Be sure you are insulated from ground and workpiece.  Cover the cover plate of the machine before power on to avoid an electric shock. ...

  • Page 5: Symbol Explanation

    Magnetic field can make cardiac pacemaker a bit wonky.  People with cardiac pacemaker should consult the doctor before carrying out welding.  Stay away from the power source to reduce the affect of magnetic filed. Improper use and operation may result in a fire or an explosion. ...

  • Page 6: Product Overview

    3. PRODUCT OVERVIEW Unique electric structure and air channel design in this series of machines can speed up the heat rejection of the power device as well as improving the duty cycles of the machines. The unique heat rejection efficiency of the air channel can effectively prevent the power devices and control circuits from being damaged by the dust absorbed by the fan, and the reliability of the machine is greatly...

  • Page 7: Order Information

    6. ORDER INFORMATION Model Function Configuration Product Code Hot start arc ignition ARC160D Z2A4 self-adaptive arc force Anti-stick MMA/Lift-TIG ARC200D Z2A5 7. TECHNICAL PARAMETERS Model Technical Unit Parameter ARC160D ARC200D Rated input AC120V±15% AC240V±15% AC120V±15% AC240V±15% voltage 50/60HZ 50/60HZ 50/60HZ...

  • Page 8: Electrical Schematic Diagram

    8. ELECTRICAL SCHEMATIC DIAGRAM g. 1 9. OPERATION CONTROL AND DESCRIPTION 1.Display meter: To show welding current normally. Showing “E-1” indicates Over current protection, “E-3” indicates over heating protection 2.TIG/MMA: To switch Lift-TIG/MMA welding mode 3. Welding current knob: To adjust the output current. 4.

  • Page 9: System Characteristics

    7.Handle 8. Power input: power input cable. 9. Power switch: Power ON/OFF switch. 10. Cooling fan. Fig. 3 10. SYSTEM CHARACTERISTICS 1) Duty cycle Rated duty cycle refers to the percentage of the normal work time of the machine under rated maximum current holding in the period when taking 10 minutes as a period.

  • Page 10: Installation, Debugging And Operation

    11. INSTALLATION, DEBUGGING AND OPERATION Note: Please install the machine strictly according to the following steps. Turn off the power supply switch before any electric connection operation. The housing protection grade of this machine is IP21S, so do not use it in rain. Please DO NOT use this machine for thawing frozen pipes.

  • Page 11: Operation

    Fig.4 Schematic Diagram of MMA Welding 1) A primary power supply cable is available for this welding machine. Connect the power supply cable to the rated input power. 2) The primary cable should be tightly connected to the correct socket to avoid oxidization. 3) Check whether the voltage value varies in acceptable range with a multi-meter.

  • Page 12: Caution

    Electrode Diameter Recommended Welding Current Recommended Welding (mm) Voltage (V) 20~60 20.8~22.4 44~84 21.76~23.36 60~100 22.4~24.0 80~120 23.2~24.8 108~148 23.32~24.92 140~180 24.6~27.2 180~220 27.2~28.8 220~260 28.8~30.4 Note: This table is suitable for mild steel welding. 12. CAUTION 12.1 Working Environment 1) Welding should be carried out in dry environment with humidity of 90% or less.

  • Page 13: Basic Knowledge Of Welding

    Welding operation is forbidden while the machine is overload. Remember to observe the max load current at any moment (refer to the corresponding duty cycle). Make sure that the welding current should not exceed the max load current. Overload could obviously shorten the machine's lifespan, or even damage the machine.

  • Page 14: Basic Operation Of Mma

    welding cable and labor protection supplies. a) electrode holder b) welding mask c) slag hammer d) wire brush Fig. 5 Tools for MMA a) Electrode holder: a tool for clamping electrode and conducting current, mainly including 300A type and 500A type. b) Welding mask: a shielding tool for protecting eyes and face from injuring due to arc and spatter, including handholding type and helmet type.
  • Page 15 his upper body from following downwards, and his arm should be separated from the costal part so as to stretch out freely. a) flat welding b) vertical welding Fig. 6 Posture in welding 3) Arc igniting Arc igniting is the process for producing stable arc between electrode and workpiece in order to heat them to implement welding.
  • Page 16 gradually moves toward the weld crater; and the electrode transversely swings. (See Fig.8) Electrode should be correctly manipulated in three movement directions after arc is ignited. In butt welding and flat welding, the most important is to control the following three aspects: welding angle, arc length and welding speed.

  • Page 17: Maintenance

    a) arc extinguishing at the outside of weld bead b) arc extinguishing on the weld bead Fig.10 Arc extinguishing modes 7) Weldment cleaning Clean welding slag and spatter with wire brush and tools the like after welding. 14. MAINTENANCE The following operation requires sufficient professional knowledge on electric aspect and comprehensive safety knowledge.

  • Page 18: Appendix A: Packing, Transportation And Storage

    Turn on the machine, the fan works, but the (1) The current potentiometer fails. Replace it. output current is unstable and can't be Check if any loose contact exists inside the machine. If any, reconnect. controlled by potentiometer when welding. (1) Check if any loose contact exists inside the machine.
  • Page 19 Description Version Time...
