CONTROLLER
MODEL RC 1T4A
(S/N 10000 and Above)
FIELD SERVICE INSTRUCTIONS
THIS DOCUMENT EMBODIES A PROPRIETARY
DESIGN ORIGINATED BY CONTROL INDUSTRIES,
INC., AND SHALL NOT BE DISCLOSED, USED, OR
DUPLICATED
MANUFACTURING
SPECIFICALLY
INDUSTRIES, INC.
RECEIVER
Rev-1
FOR
PROCUREMENT
PURPOSES,
AUTHORIZED
BY
Control Industries Inc.
614 Central Ave.
Findlay, Ohio 45840
TEL 419-800-0011
FAX 419-500-9015
OR
UNLESS
CONTROL
Advertisement
Table of Contents
Related Manuals for Control Industries RC 1T4A
Summary of Contents for Control Industries RC 1T4A
- Page 1 RECEIVER CONTROLLER MODEL RC 1T4A (S/N 10000 and Above) FIELD SERVICE INSTRUCTIONS Rev-1 THIS DOCUMENT EMBODIES A PROPRIETARY DESIGN ORIGINATED BY CONTROL INDUSTRIES, INC., AND SHALL NOT BE DISCLOSED, USED, OR DUPLICATED PROCUREMENT MANUFACTURING PURPOSES, UNLESS SPECIFICALLY AUTHORIZED CONTROL INDUSTRIES, INC.
-
Page 2: Theory Of Operation
HANDBOOK OF OPERATING AND MAINTENANCE INSTRUCTIONS RECEIVER CONTROLLER RC-1T4A 1.0 GENERAL The model RC-1T4A controller has been specifically designed to provide remote control of heliport lighting systems which require two control functions. This control system will allow the approaching pilot to select either of two operating modes at his discretion. The RC-1T4A is enclosed in a weather-proof water-tight housing and is conservatively designed for continuous outdoor unattended operation. - Page 3 FIG A Functional Diagram...
- Page 4 FIG B INTERCONNECTING WIRING DIAGRAM (with Lightning Suppression Components)
- Page 5 3.1 RADIO FREQUENCY/DECODER CARD (C.I. PART #11-0255) The radio receiver is a superheterodyne design operating at a nominal R.F. frequency within the VHF band of 118 to 136 MHz. An IF frequency of 10.7 MHz is utilized with the bandwidth controlled by a 6-pole crystal lattice filter. This filter establishes nominal -60 db rejection at adjacent channel frequencies of ±25 KHz or more.
- Page 6 3.2 RELAY CARD (C.I. PART # 11-0195): The output relays, K-1, K-2, K-3, and K-4 and their associated components, resistors R-2, R-4, R-6,R-8; indicator LED’s D-2, D-4, D-6, D-8; diodes D-1, D-3, D-5, D-7; resistors R-1, R-3, R-5, R-7 and capacitors C-1, C-2, C-3, and C-4 are contained on their own printed circuit card, P/N 11-0195.
-
Page 7: Trouble Analysis Chart
4.0 TROUBLE ANALYSIS: A malfunction chart including several possible failure modes is supplied to assist the technician in analyzing the probable cause. The receiver-controller is warrantied for one year from date of purchase. Failures not caused by improper installation or abnormal treatment will be corrected by the manufacturer free of charge within the warranty period. -
Page 8: Maintenance Concept
The unit may be maintained readily by technician level personnel. The printed circuit boards are not readily repairable in the field. Return defective printed circuit boards to Control Industries for repair / replacement by the manufacturer. A stock of one each substitute cards should be retained to verify a suspected defective card by simple substitution procedures. -
Page 9: Power Supply
16V AC. Remove the Receiver/Decoder, and Relay cards one at a time and observe the D.C. indicator. This procedure removes and isolates any possible shorts in the relay or radio boards. Recheck for proper D.C. indicator operation. If a failure remains, contact Control Industries Inc. to further troubleshoot and set up for service. -
Page 10: Timer Function
5.3.3. RECEIVER/DECODER: The Receiver/Decoder Board is printed circuit board identified as C.I. part # 11-0255. The board compromises the complete receiver, decoder, and timer functions for the unit. An effective method of determining condition of the receiver board may be accomplished by listening to the audio at the output jack identified in Figure K. -
Page 11: Installation
6.0 INSTALLATION: The receiver-controller RC-1T4A is designed for all-weather outdoor unattended operation. The weather-tight case will repel the elements and no shelter is required. Control and power lines should enter by means of the 1/2-inch conduit entry in the bottom of the unit. A maximum of five conductors is required to complete the installation. -
Page 12: Specifications
LittleFuse MDL 1 9.0 Warranty Information: Control Industries INC. Warranties that the equipment has been manufactured and will perform in accordance with applicable specifications and that any defect in design, materials, or workmanship which may occur during proper and normal use during a period of 1 year from date of installation or 2 years from date of shipment will be corrected by repair or replacement by the manufacturers f.o.b.
