- Page 1 ECO INSTANT WATER (i ) HEATER MODEL: S23, S23P INSTALLATION MANUAL * Please read manual carefully before installation. * SEERS reserve the rights to change the contents and illustrative diagrams without prior notice.
-
Page 3: Table Of Contents
CONTENT Introduction Important Safety Information Part Contents Checklist Parts Description Hand Shower Installation Guide Water requirements Installation Operating Mode Model Speci cation Troubleshooting... -
Page 4: Introduction
INTRODUCTION Congratulation! Thank you for making excellent choice by purchasing the Seers Eco Instant Water Heater. This is low power consumption water heater. The design is carefully crafted for its distinctive use in all household, hotel and any applicable vicinity. User safety is our priority in accordance to be the rst ever water heater without submersible electric heating coil. -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION THIS APPLIANCE MUST BE EARTHED, TO MAKE SURE EARTH WIRE AND HEATER UNIT HAVE PROPER GROUNDING IN HOUSEHOLD. Earthing requirements The earthing installation should be carried out in accordance with the local wiring regulation. Where EARTHING of the premises is not evident, it is necessary to run an EARTH CONDUCTOR and solidly connect an earth rod local to the installation. - Page 6 IMPORTANT SAFETY INFORMATION Cautions ! The unit must be installed by quali ed electrician and plumber. The shower heater unit must be connected to its own independent electrical circuit. Before beginning any work on the electric installation be sure that main breaker panel switch is “O ”...
-
Page 7: Part Contents Checklist
PART CONTENTS CHECKLIST Model: S23 , S23P 1 x Seers Heater Unit 1 x Shower Holder 4 x Green Wall Plug & Screw Set 1 x Hand Shower 1 x Regulator Valve 1 x Rubber Hose... -
Page 8: Parts Description
PART DESCRIPTION Model: S23 , S23P 1. AC Supply Cable Inlet 2. Regulator Valve (water Inlet) 3. Hand Shower 4. Shower Holder 5. Hose... - Page 9 PART DESCRIPTION Optional with Rain Shower 1. Rain Shower Head 2. Rain Shower Sliding Bar 3. Shower Holder 4. 3way Diverter Valve 5. Hose 6. Hose...
-
Page 10: Hand Shower Installation Guide
HAND SHOWER INSTALLATION GUIDE 1. Hand shower holder 2. Slide and remove the cover holder. 3. Position hand shower holder to desired location. FRONT VIEW 4. Mark location of the 2 holes. 5. Drill the marked holes and ll them with wall plugs. -
Page 11: Water Requirements
WATER REQUIREMENTS Plumbing Schematic Diagram Seers Eco Instant Water Heater can be tted in your home regardless of the the type of plumbing system as in most cases they can operate directly o main cold water supply. Water Storage Tank... -
Page 12: Installation
INSTALLATION The installation of the product must comply to national guidelines for electrical wiring in residential buildings. 1) Unfasten the screw at the bottom to remove front cover. 2) Drill hole on wall to mount heater according to hole position. 3) A x exible hose at outlet (red) and cold water supply to inlet (blue). -
Page 13: Operating Mode
OPERATING MODE Earth point must be connected to grounding source STEP 1: Switch ON MAIN AC SUPPLY (white indicator light ON) STEP 2: Press + or - button activate heating. P0 = O P1 = Low Temperature P2 = Medium Temperature P3 = High Temperature STEP 3: Turn ON water supply. -
Page 14: Model Speci Cation
MODEL SPECIFICATION Model Specification / Description S23P Overtemp cutoff Water flow sensor Easyfit mounting Leakproof heat module Adjustable temperature Heating element Installation: Shower holder set Hand shower set Rain shower set Optional Optional Pump Technical: Rated power 3.6 Kw 3.6 Kw Rated voltage 220~240VAc/1phase 220~240VAc/1phase... -
Page 15: Troubleshooting
TROUBLESHOOTING Please be assured that following situation is normal: 1) There will be a slight sound while the pump is in operation. (i.e model S23P) 2) Water temperature will vary according to inlet water ow rate. DESCRIPTION POSSIBLE CAUSE REMEDIES Heater not operating 1) No Power Supply 1) Check incoming power source... - Page 16 SEERS MARKETING SDN BHD (917949-V) No. 4, Jalan Utarid U5/18A, Seksyen U5, 40150 Shah Alam, Selangor Darul Ehsan, Malaysia. Tel: +603-7842 2871 Fax: +603-78439971 Email: sales@seers.com.my Website: www.seers.com.my...
