Diagram 3D NB04-W001 Assembly Instructions

North British Railway (NBR)
Perishable Goods (Fish or Milk) Van
4mm scale ("OO" "EM" or "P4")
Laser cut
MDF, card and acrylic kit.
Adhesive, paint not included. Wheels, axleguards, buffers etc. not included.
4mm scale kit suitable for "OO" "EM" "P4" etc
NB04-W001
Perishable Goods
(Fish or Milk) Van
NBR
Website:
www.Diagram3D.com
Contents This kit contains:
of this kit
1. SmartFrame
MDF parts Upper and lower frame plus alignment clips.
2. MDF body parts for this vehicle.
Cardboard panels – a total of 5 panels
Cardboard 3.
panels
There are two layers for the van sides and ends.
Layer Description
Layer 1 Window Frames and droplights
Layer 2 Van side panelling, end panelling (no steps)
Layer Description
Layer 1 Window Frames and droplights
Layer 2 Van side panelling, end panelling (with steps)
The contents of the layers above are orientated so that they cannot be confused
during assembly.
A single panel is provided containing steps and (optional) roof.
Sundry 2 x long glazing bars
Parts
Roof A 3D printed roof is included with this kit.
Axleguards The axleguard kit D3D-05 is included with this kit, pleae refer to its instructions for
assembly details.
