Page 1 User manual MINI BEAM Please read the instructions carefully before use...
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 2. Technical Specifications…………………………………………………………………………4 3. Control Menu ………………………………………………………………………………………5 4. Lamp bulb …………………………………………………………………………………………5 5. How To Control The Unit……………………………………………………………………6-8 6. Universal DMX controller control……………………………………………………………9-10 7. DMX Channels ……………………………………………………………………………………10-13 8. Dimension …………………………………………………………………………………………13 9. Trouble Shooting…………………………………………………………………………………14 10. Fixture Cleaning………………………………………………………… ………………………14 STATEMENT The product has well capability and intact packing when leave factory.
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. • Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.
Page 4: Technical Specifications
firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
Page 5: Control Menu
3.Description 1. USB socket: USB connection data. 2. Display screen: display function menus, the button will automatically lock the setting after 30 seconds of standby, to prevent operation errors, long press the MENU button for 2 seconds toactivate the button. 3.
Page 6: How To Control The Unit
5. How To Control The Unit Turn on the machine, press the ENTER button to enter the menu mode, use the UP and DOWN buttons to find the menu, when the preset menu is displayed on the display, press the ENTER button to confirm, use the UP and DOWN buttons to select the submenu, press the ENTER button to save the setting Automatically return to the previous menu.
Page 7 Drop out Standard mode 16 （CH） (Factory default) Select channel mode Reduced mode 13 （CH） horizontal 0-255 View the current channel ..0-255 Functional channel 0-255 Cance / Run DMX Mode xxxH Self-propelled mode xxxH Voice mode Scene mode automatic/1-10 Master-slave mode Auto/Master/Slave Scene selection 01-10...
Page 8 drop out Service Contact Equipment maintenance times Equipment fine-tuning Application calibration service Device data clear Equipment usage records drop out Device fine-tuning settings Select the device fine-tuning setting, press the ENTER button to confirm, the device fine-tuning setting (password: 1212), enter the initial setting menu to adjust the initial position of each motor. Press the ENTER button to confirm.
Page 9: Universal Dmx Controller Control
6.Universal DMX controller control Connection 1. In order to reduce signal errors and avoid signal attenuation and interference during transmission, a 90-120Ω (0.25W) resistor can be added between the 2-core and 3-core of the DMX output of the last machine., 2.
Page 10: Dmx Channels
to confirm, the current address will flash on the display, then use the UP/DOWN button to select the address code (1-512), press the ENTER button to save. Press the MENU button to return to the previous menu or wait 30 seconds and automatically exit the menu mode. Please refer to the following chart to set the address codes of the first 4 fixtures Fixture 1 Fixture 2...
Page 11 White light Deep red Blue 10-14 15-19 Green Orange 20-24 25-29 Magenta 30-34 Yellow 35-39 Cyan 40-44 Navy blue 45-49 50-54 Dark green 55-59 Yellow-green 60-64 CTO5600K 65-69 Four-color effect 70-75 White light → dark red (half color value 76-82 Crimson →...
Page 12 Gobo7 28-31 32-35 Gobo8 Gobo9 36-39 Gobo10 40-43 Gobo11 44-47 48-51 Gobo12 Gobo13 52-55 56-59 Gobo14 Gobo14 dithering effect, from slow to 60-64 fast 65-68 Gobo13dithering effect, from slow to fast 69-72 Gobo12dithering effect, from slow to fast 73-76 Gobo11dithering effect, from slow to fast Gobo10dithering effect, from slow to fast 77-80 81-84...
Page 13: Dimension
170-179 Gobo reset 180-189 Strobe reset Functional No function 190-199 channel 200-209 Focus/prism reset Reset all 210-229 230-239 No function 240-255 Turn off the bulb 8.Dimension...
Page 14: Trouble Shooting
9.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
