Haoyang Lighting S14-4815-SS-3R User Manual

SOLAR STRING LIGHT (Bluetooth)
Thank you for purchasing our string light.
PLEASE READ FIRSTLY AND CAREFULLY THIS USER MANUAL.
User Manual
Thank you for purchasing Solar String Light (Bluetooth control), please read this user manual carefully first,
we will introduce some of the important features and opera ons procedures of this products, please keep
this manual in a safe place for future reference.
Package Lists
1* LED String Light
1* Solar panel
1* Post & Spike
1* RF remote control
1* User manual
SPECIFICATIONS
Item No.
Solar Panel Size
Solar Panel
Working Current
Working Voltage
Charging Time
Working Time
Total Length
LED Bulb
Bulb Spacing
CCT
Waterproof Rated
Working mode
Charging mode
Control mode Smart APP + RF remote control + Bu on control
HOW TO USE
1. This solar string light can use solar or USB for charging.
2. Shortly press the bu on, the string light will be ON or OFF.
3. A er turn on the string light, shortly press the "mode" bu on again,
can change the light bulb color, and achieve different ligh ng modes.
4. The solar string light will be turned on automa cally at night.
5. The solar string light will be turned off automa cally for charging at
day me.
6. When turn on the string light, the indica ons will be always ON.
7. Three control modes: Smart APP +RF remote control+ Bu on control
Unable to Connect Troubleshoo ng
(1) Check if the power supply of the string light is normal.
(2) Check if the Bluetooth is turn on.
(3) Check if there are other mobile phone are connected, Bluetooth 4.0 only support connec ons one
to many, dose not support many to many.
(4) Check APP Bluetooth se ng if the phone is connected to the device, if connect, exit the APP and reopen,
the APP will go to connect automa cally.
(5) Normal opera ons and can not connect, please exit the APP and reopen.
(6) Exit APP, restart mobile phone, power on the string light, reopen the APP, then them will connect
automa cally.
S14-4815-SS-3R
L226 x W126 mm
3W/DC5V Polysilicon solar panel
600mA
DC3V
4-6hrs(40000Lux)
3-5hrs(A er full charge)
48FT/14.6M
S14(15pcs),0.2W/pcs
3FT/0.9M
RGB&W(2700K)
IP65
Warm ligh ng/Colorful change
Solar charging or USB charging
Charge USB
Indica on
-1-
-3-
INSTALLATION
Fix the solar panel first (Two installa on methods):
1
1. Insert the solar panel into the lawn with a post and a spike
2. With three wall screws, a ach the solar panel to the wall or the top of the wall or a tree stump
Connec ng String Lights
2
Smart APP Connec on
1. Search and Download the "HappyLigh ng" APP from APP store (for IOS) and Google play store(for Android).
2. Shortly press the ON/OFF bu on to turn on the string light, turn on the "Bluetooth" func on on your phone ,
then open the "HappyLigh ng" APP, your APP will pair with the smart string light automa cally .
3. App more func ons can be freely controlled by you.
a. Warm white mode: Warm white light brings you so and comfortable ligh ng.
b. RGB mode: RGB LED can change different light color.
c. Music mode: Lights can change colors with the beau ful rhythm of music.
d. Tape mode: Lights can be moved followed by the outside voice/music.
e. 256 scene modes can be selected.
f. Timing func on, you can set the corresponding scene to change the color of the light.
g. You can shake the phone to change the color of the light.
h. Also you can take color from the photos on the mobile phone for light transforma on.
Remote Controller Opera on
On
AUTO
S+ M+
Speed +/-
S-
R G
W
1H
Timing
2H
Remote func on descrip on
ON/OFF
AUTO: 256 scene modes can be changed automa cally
Speed +/-: Dynamic status speed +/-
Mode +/-: 256 scene modes +/-
Brightness +/-: Adjust the RGB&W brightness +/-
Timing: 1H/2H ming func on
Music rhythm mode: 8 music rhythm modes
In the white light mode, 11 preset colors can be changed cyclically.
RGBW: Click to change to relevant colors.
Note: RF Remote controller can work when the led string light not in quick blink status.
Cau ons & Warnings
1. The bulb is 3V only, please do not put the bulb into other fixtures.
2. Do not repair, disassemble, or modify the product without approval.
3. Do not place the light near any heat sources.
4. Please keep it away from children.
5. Please keep the light dry and clean.
6. Please do not hang anything from the string lights as the extra weight
may break the light wire and cause poten al fire hazard.
7. Although our lights are built with safety measures, we do not
recommended leaving the light una ended or turning on permanently.
8. Please unplug the switch when it is not in use.
9. Please cut off the power before installing the bulb.
Install cable with the empty sockets in
3
desired loca on
-2-
Off
+
Brightness +/- Mode +/-
-
B
+
Rhythm sensi vity +/-
-
Music rhythm mode
MADE IN CHINA
-4-
