Summary of Contents for AUDIFIED ToneSpot Voice Pro
- Page 1 áUDIFIED ToneSpot Voice Pro User Manual Version 1.0 shop.audified.com/products services.audified.com/download services.audified.com/support...
-
Page 2: Table Of Contents
š ToneSpot Voice Pro Table of contents Introduction What Is Included How It Works Software Installation Software Uninstallation Opening the plug-in Working with ToneSpot Voice Pro Control overview Preset management Services menu Calibration Recommended Workflow Detailed controls description Character Distortion... -
Page 3: Introduction
‣ How It Works The main value of the ToneSpot Voice Pro is in carefully tuned combinations of parameters, settings and workflow based on the analysis of thousands of world-class records. This allows you to significantly speed up your work and improve the tone of voice. -
Page 4: Software Installation
Applications folder. Software Uninstallation ‣ Windows: Navigate to the ToneSpot Voice Pro program folder in the Start menu and run the uninstaller. ‣ Mac: Open the provided disk image and run the uninstaller. Opening The Plug-in The AUDIFIED ToneSpot Voice Pro works in all main digital audio workstations (recording applications) as a plug-in. -
Page 5: Working With Tonespot Voice Pro
š ToneSpot Voice Pro Working with ToneSpot Voice Pro Control overview Input Input level section Plugin Start here! Dry mix Output level Power routing Set the input gain level so the Services control section switch signal on the input meter goes to... -
Page 6: Preset Management
Calibration ‣ Product updates ‣ Audified web site ‣ Support area on the Audified web Feedback form on the Audified web ‣ ‣ Product version and other info Calibration The Calibration value adjusts the relation between the digital zero (maximum signal value in digital systems) and the analog zero (the value which is displayed in signal meters, affecting the non-linear characteristics of the effect). -
Page 7: Recommended Workflow
š ToneSpot Voice Pro Recommended Workflow Basic 1. Set the default calibration of the plug-in according to your preferences and working headroom so the meter shows the signal being around 0 dBVU 2. Choose one of the factory presets 3. Done Advanced 1. -
Page 8: Detailed Controls Description
Add the valve distortion to your tone so it gets some extra aggression and brightness. ToneSpot Voice Pro has an advanced model of real valve distortion circuit based on vintage guitar amp. Distortion module is perfect for processing extreme voice techniques such as growling or screaming. -
Page 9: Saturation
Add the valve saturation to your tone so it gets some grit and fullness. ToneSpot Voice Pro has an advanced model of real valve saturation circuit that has almost flat response with only light high frequencies roll off and nice higher harmonics punch. -
Page 10: Punch
š ToneSpot Voice Pro Shaping controls: ‣ Low-cut knob adjusts the critical frequency of a 2nd order HPF filter ranging from 20 Hz to 250 Hz. ‣ Weight knob adjusts a peak filter with 2 selectable critical frequencies (150 Hz or 200 Hz) thanks to the frequency switch below the knob. -
Page 11: Surgery
š ToneSpot Voice Pro Surgery Sometimes you need to go really deep with some surgical EQ. -50 dB attenuation? No problem. Surgery is an extreme surgical peak EQ with 2 identical filters. The Q factor of the filters is high and can be switched to even higher Q setting by Hi Q button. -
Page 12: Effects
š ToneSpot Voice Pro Effects Need some fun? ToneSpot Voice Pro has 2 effects suitable for voice processing. Try to add Delay, Reverb, or both. Effects controls: ‣ Delay type switch is a 3-way switch with Analog, Digital and Brown modes. Those modes represent various delay colors and every mode has different stereo width when PingPong mode is activated. -
Page 13: Technical Info
Windows 7 and newer ‣ 200 MB of disk space required Conclusion We are confident that you can now work with ToneSpot. However, if anything seems unclear or you need assistance, feel free to contact us at http://services.audified.com/support Thanks for using AUDIFIED products.
