Plugload PL07 Quick Start Manual

INTRODUCTION
The PlugLoad 7-outlet Tier 1 Advanced PowerStrip
(APS) is an energy-saving surge protector that reduces
standby power wasted by TV and PC peripheral
electronics. In addition to saving energy, the APS
provides surge protection to safeguard electronics
against damaging power surges.
INSTALLATION REQUIREMENT
POWER CONNECTION
The APS features a heavy duty power cord
with an angled, space-saving plug. It must
only be
receptacle for surge protection to operate
correctly. All connected devices should be plugged
directly into the APS. Use of an extension cord, adaptor
or other power strip in conjunction with the APS will void
all warranties.
The APS may not be used with an aquarium or
evaporative / swamp cooler or any device which is likely
to cause condensation or moisture to enter the APS.
The APS must only used INDOORS in a cool dry
location. The APS should not be located directly next to a
baseboard heater where it is likely to overheat.
Any high current devices which manufacturers require to
be plugged directly into a receptacle must not be plugged
into the APS.
The total amperage of devices plugged into the APS
must not exceed 15A.
In addition to the above conditions the installation of the
APS must comply with UL installation requirements for
Relocatable Power Taps and the National Electric Code.
GETTING TO KNOW THE APS
SURGE LED INDICATOR
When illuminated green, this LED
indicates that the surge protection is
functioning normally. If this LED
extinguishes at any time, the APS
was sacrificed to protect your devices
and must be replaced.
RESETTABLE CIRCUIT BREAKER
The resettable circuit breaker
provides protection for all outlets on
the APS. If no devices are powered or
LEDs lit, press the circuit breaker to
reactivate power.
ALWAYS-ON OUTLETS
The always-on outlets receive
constant power and remain on all of
the time.
plugged into a grounded
CONTROL OUTLET
This current-sensing outlet controls
whether power is supplied to the
switched outlets or not. The control
device (e.g., TV or PC) must be
plugged into this outlet.
SWITCHED OUTLETS
The switched outlets will automatically
switch off when the control device
(e.g. TV or PC) powers off or enters a
standby state.
APS WARRANTY
The Lifetime of the APS is 3 years (hereafter referred to
as APS Warranty).
PlugLoad warrants to the original purchaser that for the
APS Warranty it shall be free of defects in design,
assembly, material, or workmanship and will repair or
replace, at its option, any defective APS free of charge.
CONNECTED DEVICE WARRANTY
PlugLoad will repair or replace, at its option, any
devices which are damaged by a transient voltage
surge/spike or lightning strike (an "Occurrence") while
properly connected
properly-wired AC power line with protective grounding
provided that the unit has been registered online for
warranty with PlugLoad.
ENSURE YOU HAVE REGISTERED YOUR APS
FOR WARRANTY BY COMPLETING AND
SUBMITTING YOU WARRANTY REGISTRATION
FORM AT WWW.PLUGLOAD.COM/WARRANTY
This Connected Device Warranty is a limited warranty,
subject to the limitations and exclusions set forth
herein. PlugLoad will spend to repair or replace the
damaged connected equipment, at PlugLoad's option,
an amount equal to the fair market value of the
damaged equipment or the original purchase price of
the equipment, whichever is less, up to the maximum
amount of $10,000.
PlugLoad reserves the right to review the damaged
APS, the damaged devices, and the site where the
damage occurred prior to processing a connected
device warranty device claim. All costs of shipping the
APS and the damaged devices to PlugLoad for
inspection shall be borne solely by the purchaser.
PlugLoad reserves the right to negotiate the cost of
repairs. If PlugLoad determines, in its sole discretion,
that it is impractical to ship the damaged devices to
PlugLoad, PlugLoad may designate, in its sole
discretion, a repair facility to inspect and estimate the
cost to repair such devices. The cost, if any, of shipping
the devices to and from such repair facility shall be
borne solely by the purchaser.
through the APS to
