HL318LC Weighing Indicator
User Manual
SH.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MERAV-6000 and is the answer not in the manual?

Questions and answers

Summary of Contents for SHEKEL MERAV-6000

  • Page 1 HL318LC Weighing Indicator User Manual SH.01...
  • Page 2 Warning Ask professional personnel to debug, detect and repair controller. Warning Please keep good grounding of controller. Warning In electrical connection of controller, please cut off the power supply in advance. Wait for 30 seconds between power-on of the controller for 2 times. Pay Attention to Static Electricity...

  • Page 3: Table Of Contents

    Contents !" TECHNICAL INDICATORS ..................... 3 #" MAIN FUNCTION ....................... 3 $" BOUNDARY DIMENSION ....................4 %" INTRODUCTION TO PANEL ....................5 &" SETTING OF PARAMETERS ....................7 ......................NTRY ETTING F1 S ..........................7 ETTING OF CALE F2 S .....................

  • Page 4: Technical Indicators

    1 、 Technical Indicators ● 6-digit 1.6-inch LCD display. Long service life and shock resistance ● 7 function keys. Operation is simple and convenient ● Protection level: IP5X ● Excitation voltage: +5VDC ● Load capacity of sensor: at most 4 350Ω simulation sensors ●...

  • Page 5: Boundary Dimension

    3 、 Boundary Dimension Instrument size : detailed in the following figure (mm); instrument weight: 1.5kg 4 、 Connector 4.1 RS232-1 and RS232-2 2Pin: TXD 3Pin: RXD 5Pin: GND...

  • Page 6: Introduction To Panel

    4.2 Load cell Connector 1Pin: +E 2Pin: +S 3Pin: SHLD 4Pin: -S 5Pin: +E 5 、 Introduction to Panel ● Introduction to indicator lamps Identification Analysis Sorting and weight check status indicator Extension indicator Counting scale indicator Animal scale indicator Accumulating scale indicator Accumulating scale...
  • Page 7 Counting scale unit Weight % indicator ● Introduction to operation keys Operation without special specification refers to short press on keys. Normal weighing state Set stage symbol Weight maintenance key->『Hold』 Short press→ F2.1 = 1, keep/cancel. F2.1 = 2, switch between percentage and Return to the weight.

  • Page 8: Setting Of Parameters

    Function key->『Func』 Flicker bit is on the Long key → Enter into setting menu. right. Tare key->『Tare』 Short key →gross weight turns to net weight. Digit flicker Indication lamp of net weight “Net” is on. position reduces. Conduct skin removal operation for multiple times.
  • Page 9 0.00 ---- 2 decimal places 0.000 ---- 3 decimal places (default value) 0.0000 ---- 4 decimal places F1.3 Number of Divisions Selectable parameters: 1 (default value), 2, 5, 10, 20, 50 F1.4 Calibration Unit Selectable parameters: 0 ---- kg (default value) 1 ---- lb F1.5 Gravitational Acceleration Selectable parameters: 9.70000~9.99999.

  • Page 10: F2 Setting Of Application Function

    ]. In the end it will display [ ] for one second, which indicates the end of null-point calibration. F1.8 Automatic Null Tracking Selectable parameters: OFF, 1 d, 2 d, 3 d, 5 d (default value) F1.9 Automatic Reset Range at Startup Selectable parameters: OFF, 2 %, 10 %, 20 % (default value) F1.10 Button Reset Range Selectable parameters: OFF, 2 %, 10 % (default value), 20 %...

  • Page 11: F3 Setting Of Energy Saving Parameters

    1 ---- Weight keeping function 2 ---- Percentage display function 3 ---- Weight checking and sorting function (default value) 4 ---- Accumulative scale function 5 ---- Counting scale function 6 ---- Animal scale function 7 ---- Peak holding function F2.2 Empty-scale threshold value Selectable Parameters: 0~ full range (default value: 0.001) F2.3 Target Weight for Weight Checking and Sorting Selectable Parameters: 0~ full range (default value: 2.000)

  • Page 12: F4 Setting Of Serial Port

    Serial-port Setting F4.1 UART0 Communication Interface Parameter F4.1.1 Communication Mode Selectable Parameters： ---- command out ---- continuous output ---- Key output F4.1.2 Setting of Data and Check Pit Selectable Parameters:：8_N_1 ---- 8-pit no parity check (default value) 7_E_1 ---- 7-pit odd parity check 7_O_1 ---- 7-pit even parity check 8_E_1...

  • Page 13: Function Description

    F5.1 Key test Instrument display 【 】 , press 『 Print』 、 『Zero』 、 『Tare』 、 『Gross』 、 『lb/kg』 、 『Total』 in order, and the instrument displays 【 】、 【 】、 【 】、 【 】、 【 】、 】，press 『Hold』 to quit key test. 【...
  • Page 14 If the weight is locked, press 『Hold』 again to unlock and it goes back to normal weighing mode and “Hold” indicator goes off. In weight locked status, it refuses to tare, clear tare and zero. ● Percentage display F2.1 = 2 Display introduction Displaying 【...
  • Page 15 the accumulated value; then it goes back to normal weighing status. If it displays 【 】 for one second and then goes back to normal weighing mode, it means invalid operation! Causes: 1. The scale must be zeroed between two successive accumulation operations, otherwise, accumulation will be refused.
  • Page 16 ● Animal scale functions F2.1 = 6 Operation method In normal weighing state, place the animal on the weighing platform and its weight must be ≥threshold value set in F2.2. Press 『Total』, instrument will collect data sampling. After sampling, the average value of sampling data will be locked, showing X.XXX kg;...

  • Page 17: Appendix 2. Printing Format Specification

    instruments of the factory. The calibration input Input≥10 % weight of full range 【 】 weight is too small The weight in calibration is Load≥10% weight of full range 【 】 too light The scale is dynamic in Inspect the scale body 【...
  • Page 18 points 0x0d example： 1、0x28 0x2b 0x29 0x30 0x30 0x31 0x32 0x38 0x2e 0x35 0x0d show 128.5 2、0x28 0x2d 0x29 0x30 0x30 0x31 0x32 0x38 0x2e 0x35 0x0d show -128.5 3、0x28 0x2b 0x29 0x30 0x30 0x31 0x32 0x38 0x31 0x35 0x0d show 12815 4、0x28 0x2d 0x29 0x30 0x30 0x31 0x32 0x38 0x31 0x35 0x0d show -12815...
  • Page 19 F2.1 = 3 selection, check weight, press 『Print』： REPORT REPORT REPORT ----------------------- ----------------------- ----------------------- Gross 1.980kg Gross 2.000kg Gross 2.020kg State Less State State Over Underweight Qualified Overweight F2.1 = 4 accumulation scale, print detailed statement or format of total weight: Print details and total weight Only print total weight REPORT...
