MEMO2GO Handling Instructions Level 1

The following steps are recommended to achieve an effective and trouble-free installation and operation of your

MEMO2GO system:

Prepare a consignment (in the Carpenter Workshop)

Controller

Antenna

- Take required items from inventory

- Connect items as shown above

- Program ACCESS CHIP CARDS and ACCESS KEY FOBS

on all controllers of this consignment. Refer to page 5

of this manual

MEMO2GO Handling Instructions Level 1

Power Supply

- Program SPECIAL CHIP CARDS on all controllers of this

consignment. Refer to page 4 of this manual

- Change CONTROLLER SETTINGS on all controllers of this

consigment (if necessary). Refer to page 6 and 7 of this

manual - otherwise use factory settings

V 1.5

13-04-2018

Table of Contents

Need help?

Do you have a question about the MEMO2GO and is the answer not in the manual?

Questions and answers

Summary of Contents for DIAMOND MOTION MEMO2GO

Page 1 MEMO2GO Handling Instructions Level 1 The following steps are recommended to achieve an effective and trouble-free installation and operation of your MEMO2GO system: Prepare a consignment (in the Carpenter Workshop) Power Supply Controller Antenna - Program SPECIAL CHIP CARDS on all controllers of this...
Page 2 A. Check that the lock can’t be manipulated from the outside. to the front side B. Take care that the Locks are catching the door safe, re-lock correct if door was not opened MEMO2GO Handling Instructions Level 1 V 1.5 13-04-2018...
Page 3 FURNITURE NAME/NUMBER - Hand over ALL SPECIAL CHIP CARDS and ACCESS CHIP CARDS / KEY FOBS to Shop Managers - Handover the MEMO2GO Handling Instructions to the - Make the Shop Managers aware that the MASTER Shop Managers...
Page 4 Between steps 2 and 5 if the Card is not presented within 10 seconds and the next Beep-tone sounds, it is too late. The programming on the particular card will be skipped MEMO2GO Handling Instructions Level 1 V 1.5 13-04-2018...
Page 5 Key Fob at the Normal at the Antenna Antenna Antenna Antenna Operation Erasing Keys All Access Keys Decoration Card Supervisor Card are Erased Present the Erasing Ready for Normal Card at the Antenna Operation MEMO2GO Handling Instructions Level 1 V 1.5 13-04-2018...
Page 6 Press Press Press Present the Master Ready for Normal Card at the Antenna Operation Example Configuration with 12-Button Hand Terminal Type Code: E 2 1 E To change configuration: Lock Activation seconds MEMO2GO Handling Instructions Level 1 V 1.5 13-04-2018...
Page 7 One Door Only Mode ON E138E1E One Door Only Mode OFF E138E0E Key Opening Mode ON E81E1E Key Opening Mode OFF E81E0E Separated Antennas ON * E202E1E Separated Antennas OFF * E202E0E * if applicable MEMO2GO Handling Instructions Level 1 V 1.5 13-04-2018...
