LINENFOLD DARK OAK HOME BAR (COMPLETE) 494564

Notes before assembly:

a) The back section of this item should be located against a wall and
secured.
b) Do not try to assemble this item on your own.
c) You will need at least two other people to assist you lifting the
components into place.
d) You will also need steps for attaching the top sections.
e) Assembly should be carried out in the items final location
f) Check that all the parts are present as listed before beginning assembly.
Should any parts be missing please immediately contact the dealer
where you purchased your item.
A. Front left unit. B. Front center unit.
G. Base back right unit. H. Top back left unit. I. Top back center unit. J. Top back right unit.
L. Top front left unit.
USER GUIDE FOR
L
H
F
C. Front right unit. D. Door unit.
M. Top front center unit.
K
D
A
E. Side untit.
K. Top back unit.
N. Top front right unit.
M
N
G E O
C
B
F. Base back left unit.
O. Post
unit.
