Summary of Contents for EXPOL ATLAS
- Page 1 MANUAL ATLAS...
- Page 2 Dear customer! Thank you for buying “Garant Triumph sectional Modular Arc” greenhouse which was developed specifically for backyards and garden patches and features a simple and reliable design. Zinc-coated frame sections are resistant to harsh weather conditions. Strong and flexible polycarbonate guarantees reliable side wind protection and appropriate microclimate for your crops.
- Page 3 Quantity per one Part greenhouse, pcs. Part name 4 m 6 m 8 m 10 m 12 m End-walls with a door and a vent Arcs End crossbar (without connecting bends) Crossbar (with connecting bend on one end) Latches (for doors and vents) Tower bolt (for connection doors and vents) Hinges (for doors and vents) Bolts М6×65 (or М6×70) mm with a washer and a nut (for interconnecting arcs...
- Page 4 later frame assembly steps. The nut and the washer are mounted from the inner greenhouse side (under the arc). A wrench size 10 is required for the installation. Other elements are fastened to each other using screws with pressure pads on the inner side of the greenhouse and using roof screws on the outer side of the greenhouse (for attaching polycarbonate sheets).
- Page 5 Figure 2 – Types of element connections for the greenhouse frame end-walls (view from the inside of the greenhouse)
- Page 6 Step 2. Covering of end-walls using the cellular polycarbonate sheets Before attaching polycarbonate to the frame end-walls, familiarize yourself with the general rules for mounting cellular polycarbonate sheets. General rules for mounting cellular polycarbonate sheets Cellular polycarbonate sheets are attached to the frame using the roof screws with a rubberized washer.
- Page 7 After fixing the polycarbonate sheets, mount the hinges, latches, tower bolts, and hooks on the door and the vent (Figure 4) using screws with a pressure pad (Figure 5). The latches are used to fix the doors and vents in the closed position. The tower bolt is used for connecting the door and the vent into a single unit, which can be easily opened or closed (for example to conveniently enter the greenhouse).
- Page 8 Before assembling the frame, its end-walls must already be covered with the polycarbonate sheets. The end-walls and the intermediate arcs are connected to each other with 5 rows of the connecting elements (crossbars) using bolts, washers, and nuts through the drilled holes. A wrench size 10 is required for the installation.
- Page 9 The polycarbonate sheets are to be mounted after the frame assembly is completed. First mount the side sheets, then the middle ones; it is required that the sheets are oriented in such a way that the bending direction follows the cell direction (Figure 6). Mount the sheets so that they overrun the end arcs (end-wall arcs) by at least 5 cm.
- Page 10 Foundation Figure 9 – Foundation sizing Due to continuous refinement of the “Garant Triumph sectional Modular Arc” greenhouse design, the manufacturer reserves the right to change the design without prior notice. The product is intended for private use, and not for public (commercial) use. Purchase data: _______________________ Seller:_____________________...
