Installation
& Assembly
Instructions
AMERIVENT ®
These are the three
ways to install
AmeriVent
Model HS/HSS
all-fuel chimney.
A MAJOR CAUSE OF CHIMNEY-RELATED FIRES IS FAILURE
TO MAINTAIN REQUIRED CLEARANCES (AIRSPACES) TO
COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE
THAT THIS CHIMNEY BE INSTALLED ONLY IN ACCORDANCE
WITH THESE INSTRUCTIONS.
Do not install chimney without first reading these
instructions very carefully.
• AmeriVent Model HS/HSS all-fuel chimney systems meet
the requirements of UL Standard #103 HT when installed in
accordance with our installation instructions. AmeriVent
Model HS/HSS all-fuel chimneys are designed to be
installed as complete systems, including supports, pipe
sections, caps, firestops, attic insulation shields, etc.
• The AmeriVent Model HS/HSS all-fuel chimney construction
consists of three walls of metal, using air and woven ceramic
fiber blanket insulation. The inner and intermediate walls are
stainless steel, and the outer wall is galvanized steel. This
chimney is listed (UL 103 TYPE HT) for venting flue gases
not exceeding 1000°F under continuous operating
conditions. In addition, UL has conducted additional tests at
1400°F for one hour and 2100°F for 10 minutes to verify
compliance with UL test standards. The Model HS/HSS all-
fuel chimney is approved, accepted, or listed by UL, NFPA,
IMC and UMC.
Model HS/HSS Factory-Built Chimney
• The AmeriVent Model HS/HSS all-fuel chimney is suitable
for use on the following types of wood, coal and oil
appliances.
Residential Appliances
Ranges, warm-air furnaces, water heaters, hot-water
heating boilers, 15 psi or less steam boilers, floor furnaces,
wall furnaces, room heaters, and fireplace stoves.
Building Heating Appliances
Nonresidential building heating appliances, steam boilers
operating at not over 1000°F flue gas temperature.
• The Model HS/HSS Chimney may also be used where type
B gas vents are permitted, but should not be used for
forced- draft or induced-draft appliances that have a
positive pressure in the vent.
• Installing or using our chimney or parts of our chimney in
ways other than those specified in our instructions might be
hazardous; therefore, the chimney must be installed exactly
as shown in these instructions.
This symbol on the product
means the product is listed by
Underwriters Laboratories, Inc.
1
