AGRIPO LARGE 250 KG User Manual

Electronic lift system

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

USER GUIDE

Quality controlled and

approved by:

ID NO:

UNIT NO:

Table of Contents

Need help?

Do you have a question about the LARGE 250 KG and is the answer not in the manual?

Questions and answers

Summary of Contents for AGRIPO LARGE 250 KG

Page 1 USER GUIDE Quality controlled and ID NO: approved by: UNIT NO:...
Page 3 USER GUIDE ELECTRONIC LIFT SYSTEM LARGE 250 KG / SMALL 100 KG Editor: Fredric Jansson Issuer: Robert Dahm Name: Translation of the original / Översättning av bruksanvisning original Revision: H Created: 2015-10-01 Updated: 2022-06-03...
Page 5: Table Of Contents
TABLE OF CONTENT INTRODUCTION ........................6 INSTALLATION / START UP ................... 7 PALLET LEG EXTENSIONS ..................... 8 ROLLER LEG EXTENSIONS .................... 8 SAFETY ............................9 OPERATION ........................... 10 MAINTENANCE ........................11 CABINETS FOR LIFTS ......................11 MECHANICALLY LOCKED ....................11 ELECTRICAL DRAWING ....................13 DECLARATION OF CONFORMITY ................15...
Page 6: Introduction
For all other information and fault finding, contact Intrx. Manufacturer: Interior Experts Sweden AB Järsjögatan 9 SE - 692 35 Kumla Tel: +46 19 57 80 80 Email: info@Intrx.com Web: www.agripo.se / www.Intrx.com...
Page 7: Installation / Start Up
Installation / Start up Remove the packaging material. Take out the stainless steel disk Lift off the electrical lift from pallet When moving the electrical lift with a forklift, the elevator box must be lifted about 100 mm so the forklift legs can be fully moved under electri- cal lift The electrical lift Large / Small should be placed against a fixed, straight wall or similar to avoid displacement when installing or removing pallets...
Page 8: Pallet Leg Extensions
Pallet leg extensions When using a pallet Roller leg extensions When using a container with wheels.
Page 9: Safety
Safety The dispenser is designed and manufactured according to valid safety regu- lations, i.e the CE declaration • The lift must be located and installed as described on page 5. • To avoid injuries the operator must always supervise the dispenser when rising and lowering the elevator box and make sure no unauthorized per- sonnel is close to the machine.
Page 10: Operation
Operation Operating switch for up and down movement Turn left (1) for moving down and turn right (2) for moving up. Reset button Reset at overloaded engine Emergency stop Push in for stop and turn clockwise for reset. The elevator box stops at pre-set locations.
Page 11: Maintenance
Maintenance Actions at MALFUNCTION Make sure the power cord is plugged in Check that the emergency stop is not activated (pressed). Turn to release Press the reset button (about 20-30 seconds), then release and attempt to start the machine again. Other malfunction: If the elevator box has passed the upper or lower limit and stucked, see pictures to check the breakers.
Page 12 Emergency Stop: check that it is not pressed. Reset button: pressed about 20 seconds at stop. 2 switches > located at the top When troubleshooting: if it and bottom of the left side. turns out that the switch is in Must be in neutral.
Page 13: Electrical Drawing
Electrical drawing...
Page 15: Declaration Of Conformity
Declaration of conformity This product Large 250 KG / Small 100 KG is designed and manufactured in accordance with current safety regulations, according to the CE directives. Machinery Directive 2006/42 / EC, Annex II, 1A AFS 2008:3, Annex IIA EG 1935/2004 materials and articles intended to come into contact with food...
Page 16 Intrx Visit: Järsjögatan 9 Kumla, Sweden Mail: Box 140, SE-692 23 Kumla, Sweden Office: +46 (0)19 57 80 80 Email: info@intrx.se www.intrx.se www.agripo.se...

This manual is also suitable for:

Small 100 kg
