- Page 1 Powerley Thermostat SKU: PWLY-7828-A1...
-
Page 2: Quick Start
FAIL will scroll across the thermostat display if inclusion is unsuccessful, or if process takes longer than 1 minute. See the next page for troubleshooting.To learn more about which Z-Wave command classes this thermostat supports, visit:www.powerley.com/thermostat/command-classes Attention: This manual is automatically generated from Z-Wave Alliance Product data and may be incomplete. -
Page 3: What Is Z-Wave
Bridge to facilitate communication and control between the devices. The thermostat provides the user with the ability to remotely control home temperature and also allows Powerley to optimize the HVAC system's use balancing energy usage and comfort. The device also provides for the ability to facilitate Demand Response events, including allowing the consumer to choose whether or not to participate in the event via push notifications. - Page 4 1 minute. See the next page for troubleshooting.To learn more about which Z-Wave command classes this thermostat supports, visit:www.powerley.com/thermostat/command-classes Exclusion Z-Wave Exclusion ProcessTo exclude your Thermostat, press and hold Mode for 5 seconds to initiate Z-Wave exclusion process.
-
Page 5: Quick Troubleshooting
of the up/down arrows. SUCCESS will scroll across the thermostat display once excluded.NOTE: Excluding the thermostat will restore it to the default state for Z-Wave and temperature set points. Quick trouble shooting Here are a few hints for network installation if things dont work as expected. 1. - Page 6 Parameter 1: Display Units This configuration setting controls the units of which the temperature is displayed in. Size: 1 Byte, Default Value: 1 Setting Description Parameter 10: OTA (Over The Air) programming error code This configuration setting gives feedback on the status of an OTA programming update. Size: 1 Byte, Default Value: 0 Setting Description...
- Page 7 Setting Description 1 Stage Conventional 2 Stage Conventional Heat Pump w/ O-Wire Heat Pump w/ B-Wire Heat Pump w/ O-Wire & aux heating Heat Pump w/ B-Wire & aux heating Parameter 3: ECO Mode this configuration setting displays if the thermostat is currently operating in ECO Mode. Size: 1 Byte, Default Value: 0 Setting Description Parameter 4: Thermostat Default Settings...
-
Page 8: Technical Data
Medium High Auto Parameter 7: Demand Response Mode This configuration setting controls the LED indicator light to signify the thermostat setpoint is part of a utility-set Demand Response Event. Size: 1 Byte, Default Value: 0 Setting Description Parameter 8: Swing Setting This configuration setting allows the user to control at what setpoint variance the HVAC systemturns on at.The thermostat swing temperature is in units of 1 degrees Fahrenheit. -
Page 9: Supported Command Classes
Sensors Humidity Thermostat HVAC Systems Supported Heat PumpMulti StageSingle Stage Thermostat Power Source BatteryPower Stealing (hard-wired 24V) Color White Communications Protocol Z-Wave Serial API Firmware Updatable Updatable by Manufacturer Thermostat Modes CoolEnergy Save CoolEnergy Save HeatHeat Frequency XXfrequency Maximum transmission power XXantenna Supported Command Classes •... - Page 10 Node Information Frame — is a special wireless message issued by a Z-Wave device to • announce its capabilities and functions. (c) 2019 Z-Wave Europe GmbH, Antonstr. 3, 09337 Hohenstein-Ernstthal, Germany, All rights reserved, www.zwave.eu. The template is maintained by Z-Wave Europe GmbH.
