- Page 1 OWNER’S MANUAL ULTRASONIC WARNING SYSTEM 913-599-9040 | OEAttachments.com...
-
Page 3: Table Of Contents
OWNER’S MANUAL ULTRASONIC WARNING SYSTEM Model. UPD-K01 Table of Contents Caution/Warning for Safety Components Installation How to Connect Products Operation Principle How to Use Indicator Specifications Warranty MODEL: SERIAL NUMBER: (Located on data plate attached to the unit frame) DATE PURCHASED:... -
Page 4: Caution/Warning For Safety
Do not touch the Do not place heavy connector or wiring objects on the product with wet hands. or wiring. It may cause This may cause electric shock or fire. electric shock or fire. OEA SafeGuard... - Page 5 Owner’s Manual If a connector or a Do not disassemble or wiring gets wet, wipe modify this product. it with a dry towel. This may cause trouble, Otherwise, it may and After- Sale Service cause electric shock will not be available. or fire.
-
Page 6: Components
[Set 2] Sensor Cable *Screws excluded in the product component. Product Diameter of Screw Hole Diameter of Screw Quantity Required Ultrasonic Sensor Ø 0.25in Ø 0.24in 4EA (2EA/sensor) Indicator Ø 0.28in Ø 0.24in Horn Speaker (optional) Ø 0.46in Ø 0.39in OEA SafeGuard... -
Page 7: Installation
Owner’s Manual INSTALLATION • Indicator: Installed near the • Sensor: Installed outside (in rear, driver seat. front or side) of the vehicle. OEAttachments.com 913-599-9040... -
Page 8: How To Connect Products
It may cause a malfunction by liquid matters if disregarding it. Optional Horn Speaker ▶ Yellow : Rear Det. ▶ Red : (+) Power ▶ Black : (-) Power Fuse [Set1] Sensor 1 Indicator [Set1] Sensor 2 Optional [Set2] Sensor 1 Optional [Set2] Sensor 2 OEA SafeGuard... -
Page 9: Operation Principle
Owner’s Manual OPERATION PRINCIPLE Detect obstacles within 3ft Indicator “Beep Beep Beep Beep” Fast Tempo Horn Speaker (Optional) 10ft “Watch out. Danger.” Voice Alarm Detect obstacles within 7ft Indicator “Beep-- Beep-- Beep--” Medium Tempo Horn Speaker (Optional) “Watch out. Danger.” 10ft Voice Alarm Detect obstacles within 10ft... -
Page 10: How To Use Indicator
• Mode Button ON (Light ON): Sensors activated only when the the indicator and the horn speaker is changed at once.) reverse gear operates • Change the volume level using Volume Buttons. (The volume of the indicator and the horn speaker are changed together.) OEA SafeGuard... -
Page 11: Specifications
Owner’s Manual SPECIFICATIONS Horn Speaker Specifications Ultrasonic Sensor Indicator (optional) Model UPD-K01-01 UPD-K01-11 1-3202-00003 Product Image Power DC 10.5V 12 / 24Vdc Current - 9 ~ 32Vdc Below 24W (Including Power Consumption Horn Speaker Output) Speaker Output Impedance 8ohm Interface LIN 2.1 Slave(USS.2) -
Page 12: Warranty
GENERAL The OEA Limited Warranty is extended only to the original purchaser and may be void in the event that the product is sold or otherwise transferred. No warranty will apply to any product that has been (i) modified, altered, or adapted without OEA’s written consent, (ii) abused or misused, (iii) repaired by any third party in a manner that fails to meet OEA’s repair standards, (iv) improperly installed, or (v) used with... - Page 13 Owner’s Manual NOTES OEAttachments.com 913-599-9040...
- Page 14 Owner’s Manual OEA SafeGuard...
- Page 15 Owner’s Manual OEAttachments.com 913-599-9040 June 13, 2022...
- Page 16 913-599-9040 | OEAttachments.com 1 6 0 0 0 W e s t 1 0 8 t h S t r e e t , L e n e x a , K a n s a s 6 6 2 1 9...
