smart acoustic SMK61 User Manual

Controller keyboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SMK61
CONTROLLER KEYBOARD
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMK61 and is the answer not in the manual?

Questions and answers

Summary of Contents for smart acoustic SMK61

  • Page 1 SMK61 CONTROLLER KEYBOARD USER MANUAL...

  • Page 2: Table Of Contents

    SMK61 SPECIFICATIONS . . . . . . . . . . . . . . . . . . .

  • Page 3: Introduction

    SMK61 SPECIFICATIONS Multi-functional 61 Key Controller Keyboard Š Assignable Components (Slider, Pedal, Pitch Bend, Modulation Wheel, / Š Buttons, Knobs) Š Driver Free, Plug and Play Support Compatible with Windows and MAC OS X | OS Š Compatible with Major Sequencer Software Š...

  • Page 4: Front Panel Description

    FRONT PANEL DESCRIPTION KEYBOARD PEDAL PEDAL ALL SOUND ALL NOTE RESET ALL ASSIGN CHANNEL PROGRAM BANK MSB BANK LSB RPN MSB RPN LSB NRPN LSB DATA MSB DATA LSB MUTE SNAP SHOT UPLOAD DUAL SPLIT GM ON GM2 ON GS ON XG ON CLEAN ENTER...

  • Page 5: Back Panel Description

    BACK PANEL DESCRIPTION 1 . MIDI OUT: MIDI output interface (Use this to connect the keyboard to other midi hardware). 2 . USB: USB interface (This will send midi data to computer for use with external sequencer) 3 . PEDAL: Assignable pedal interface, for switching or continuous pedal controls (Works on global midi channel).

  • Page 6: Functions

    ASSIGNING THE KEYBOARD AND USING THE IN-BUILT FUNCTIONS The majority of the functions of the keyboard can be easily executed by pressing the grey EDIT button, followed by a command key under the CONTROL / FUNCTION / RESET menus, then by entering the desired numerical value using the NUMBER keys, followed finally by the ENTER key.

  • Page 7: Program

    PROGRAM This function is used to send a program change to an external midi device. To send a program change enter the following sequence.. EDIT, PROGRAM, NUMBER (enter the patch / preset number you desire), ENTER. * Note – The first rotary encoder (A1) is already set up to do this function when the keyboard is sent from the factory.

  • Page 8: Nrpn

    NRPN NRPN stands for "Non-Registered Parameter Number" and is part of the MIDI specification for control of electronic musical instruments. NRPNs allow for manufacturer-specific or instrument-specific MIDI controllers that are not part of the basic MIDI standard. Unlike other MIDI controllers (such as velocity, modulation, volume, etc), NRPNs require more than one piece of controller data to be sent.

  • Page 9: Rpn/Nrpn

    RPN/NRPN Use RPN MSB, RPN LSB, DATA MSB and DATA LSB to send RPN message. Use NRPN MSB, NRPN LSB, DATA MSB and DATA LSB to send NRPN message. As explained -(in section---------) any controller can be used to adjust these controllers if previously assigned to the preset.

  • Page 10: Snap Shot

    BUILT FUNCTIONS (page 5) to activate it. UPLOAD/DOWNLOAD The SMK61 can send and receive all configuration data in form of SysEx strings. To make use of that, a SysEx-compatible sequencing software that can receive and transmit SysEx data is needed. Make sure in MIDI filter settings in your software that Sys Ex data is not filtered out.

  • Page 11: All Sounds Off

    ALL SOUNDS OFF In case of abnormal constant sound from the system or external sound module, perform the all sounds off function. Refer to ASSIGNING THE KEYBOARD & USING THE IN-BUILT FUNCTIONS (page 5). RESET ALL CONTROLLERS Refer to ASSIGNING THE KEYBOARD & USING THE IN-BUILT FUNCTIONS (page 5). GM ON GM initialization message.

  • Page 12: Appendix Of Controls

    APPENDIX APPENDIX 1 ASSIGNABLE CONTROLLER LIST ITEM CHANNEL INITIAL CONTROLLER INITIAL RANGE CHANNEL RANGE CONTROLLER 1 16 GLOBAL 0 159 (OCTAVE) 156 SLIDER CHANNEL 0 153 (VOLUME) 7 PITCH 0 153 (PITCH) 142 MODULATION 0 153 (MODULATION) 1 PEDAL 0 153 (SUSTAIN) 64 0 159 (PROGRAM) 154...
  • Page 13 APPENDIX APPENDIX 2 CONTROLLER LIST CONTROLLER NO . DEFINITION VALUE RANGE (MSB) BANK SELECT 0 127 (MSB) MODULATION 0 127 (MSB) BREATH MSB 0 127 (MSB) UNDEFINED 0 127 (MSB) FOOT CONTROLLER 0 127 (MSB) PORTAMENTO TIME 0 127 (MSB) DATA ENTRY 0 127 (MSB) CHANNEL VOLUME 0 127...
  • Page 14 APPENDIX APPENDIX 2 CONTROLLER LIST CONTD . CONTROLLER NO . DEFINITION VALUE RANGE (LSB) GENERAL PURPOSE CONTROLLER 1 0 127 (LSB) GENERAL PURPOSE CONTROLLER 2 0 127 (LSB) GENERAL PURPOSE CONTROLLER 3 0 127 (LSB) GENERAL PURPOSE CONTROLLER 4 0 127 52-63 (LSB) UNDEFINED 0 127...
  • Page 15 APPENDIX APPENDIX 2 CONTROLLER LIST CONTD . CONTROLLER NO . DEFINITION DEFINITION (MSB) RPN 0 127 102-119 UNDEFINED 0 127 ALL SOUND OFF RESET ALL CONTROLLERS LOCAL CONTROL 0 FF , 127 ON ALL NOTES OFF OMNI OFF OMNI ON MONO POLY (RPN) PITCH BEND SENSITIVITY...
  • Page 16 APPENDIX APPENDIX 2 CONTROLLER LIST CONTD . CONTROLLER DEFINITION VALUE RANGE NO . GLOBAL CHANNEL 1-16 OCTAVE -3 3 TRANSPOSE -12 12 KEYBOARD CURVE PEDAL CURVE 1-127 APPENDIX 3 LED STATUS LIST NO . STATUS DEFINITION 3 Digit Display Upper Transpose Value Lower Transpose Value Upper Octave Value Lower Octave Value...
  • Page 17 SAFETY INFORMATION PAGE...
  • Page 18 USER MANUAL...
