Summary of Contents for EV-OPTIMIZER EV-OPTIMIZER
- Page 1 Installation manual Home & Business 02/2021 V1.0...
- Page 2 EV-Optimizer This document contains information only and is a non-binding offer by EV-Optimizer. EV-Optimizer has prepared the content of this document to the best use of its knowledge. We cannot provide any implicit or explicit guarantee for the completeness, accuracy, reliability, or suitability of the content, and for the products and services that are mentioned here for a particular application.
-
Page 3: Table Of Contents
Manual Content Home/Business Installation EV-Optimizer Installation with current transformers Installation with P1 port New RS485 interface on Elvi G4 Connection Main fuse or circuit breaker Troubleshooting LED Indication Correct cable specification Installation manual Home & Business... -
Page 4: Home/Business
Available in a range of 25 to 80A. Installation EV-Optimizer There are two ways to install the EV-Optimizer. Both ways are explained step by step. If you are using the P1-port, you may continue with ‘installation with P1-port’ (page 6). If you are using current transformers, you may continue with ‘installation with current transformers’. -
Page 5: Installation With Current Transformers
Step 5 Determine where the clamp of the EV-Optimizer will be placed and attach it to the wall using the fixing materials. Step 6 Put the EV-Optimizer into the holder. If there is not enough space, there is a horizontal brace available. -
Page 6: Installation With P1 Port
Attach the 2 wires from 1 wire pair of the SF-UTP cable in the orange plug as shown on image 4 (page 5) and insert the plug into the corresponding RS485-port (2) on the EV-Optimizer. See image 3 (page 5). Ensure that the 2 wires correspond with the connected wires on the modem in the supply station. -
Page 7: New Rs485 Interface On Elvi
New RS485 interface on Elvi The new Elvi-hardware contains an external RS485-interface that can be connected through a Dynamic Load Balance-system such as the EVBox Smart Charging. Often the RS485-interface uses a fixed serial cable. This cable is mostly a CAT5 / CAT6-networkcable of which 2 wires (A and B) are connected to the terminal strips 3 and 4 on the DIN-rail in the Elvi Walldock. -
Page 8: G4 Connection
G4 Connection The EV-Optimizer is connected to the EV-Box G4 series with other connectors. This one is made for 2 instead of 4. The wire pair is connected in the same way as the connector with 4 pins. See image 4, page 5. -
Page 9: Main Fuse Or Circuit Breaker
First, determine whether the main fuse contains a fuse or a circuit breaker. Now that the EV-Optimizer has been installed, you can verify if it is placed in the right way. If it concerns a fuse, there should be 2 lights turned on. -
Page 10: Troubleshooting Led Indication
The flashing speed is equal to the power consumption. If the power usage goes up, theLED indicator will flash faster. Continuing green (of the first light): The EV-Optimizer is still in programming mode The second lamp needs to be constantly turned on, if it concerns a fuse. Put the rotary switch (in the EV-Optimizer) from 5 to 6 inside the EV-Optimizer.
