- Page 1 MANIKK SHMIX level shifting mixer Users Guide...
- Page 2 M A N I K K S H M I X Users Guide Document version 0.1 ã 2019 manikk SWEDEN...
-
Page 3: Table Of Contents
T able of Contents Frontpanel layout ............... 1 Welcome ..................2 Front panel controls and jacks ........... 3 Inputs ..................3 Outputs ..................3 Back panel connectors .............. 4 Power connector ................ 4 Pin header ................. 4 Converting to an AC-mixer ............5 Technical details ................ -
Page 4: Frontpanel Layout
M A N I K K S H M I X Frontpanel layout... -
Page 5: Welcome
Welcome Congratulations to your purchase of this module. The module is a six channel, mono, DC mixer with separate outputs for the mix and level-shifted mix. Separate knobs for all 6 inputs, the main mix out and the level shifted output. Pin headers on the backside for additional connectivity. -
Page 6: Front Panel Controls And Jacks
Front panel controls and jacks Inputs The mixer has 6 inputs. Each input can be attenuated by a dedicated attenuator knob. All knobs are linear. Outputs The man level of the mix can be controlled by the “Master” knob and the mixed signal is fed to the Mix jack. -
Page 7: Back Panel Connectors
Back panel connectors Power connector The power connector should be connected to the Eurorack power supply bus with the supplied ribbon cable. Warning! Make sure that the polarization will be correct. The red stripe is -12V and should be oriented to the side indicated on the PCB. Pin header All functions have a pair of pins on the backside. -
Page 8: Converting To An Ac-Mixer
Ch4 in Channel 4 in If you insert a cable in the front input 4 jack, the signal from the ch4-in pin is broken. Ch3 in Channel 3 in If you insert a cable in the front input 3 jack, the signal from the ch3-in pin is broken. -
Page 9: Technical Details
Technical details Width: 6HP Current consumption: +12V: 7,2 mA -12V: 7,2 mA More information You can find more information on the website manikk.com: • Latest version of this manual • FAQ • Other products • And more… Warranty This device has a one (1) year limited warranty starting from the first purchase date. - Page 10 Very important that you attach your return-address to the device, so we know where to return the repaired device. 4) Manikk will repair or replace the device if the problem is covered by the warranty. We will send the repaired device back to you.
