AMERICAN IMAGE DISPLAYS ShowStopper Deluxe 10 x 20 Quick Start Manual

ShowStopper Deluxe 10' x 20' Tent
Product Specifications
Thermal Peak Maximum Imprint
Thermal Overhang Maximum Imprint
Canopy Color: White
Dimensions: 236" w x 125" h up to 138" h x 118" d

Product Parts

1 - Frame
2 - Canopy

Set-Up

Step 1
Remove the tent from the bag and placing it at your
desired location.
In tandem with another person, separate the legs of the
tent until they are extended a full arms length.
Step 3
Separate the frames legs. About halfway open, attach
the loop in the middle of the Canopy (2) to hook on the
middle legs on each side. Continue to open the frame
until fully extended. The frame will open a little at a time so
alternate ends until the Frame (1) no longer expands.
: 46" w x 17" h
: 60" w x 8" h
2
1
Instructions Continued On Back Side
Step 2
Unfold your Canopy (2) and drape over the tent' s Frame (1).
Attach the Canopy (2) by connecting the loop strips on the
canopy corners with the hook strips on the frame' s four legs.
Position the canopy' s apex with the center poles of the Frame (1).
Step 4
Lift the expanding section
of the frame upwards until
the sliding connectors lock
into place on the frame's
legs.
4/12
