ARTESIAN BUILDS PLUTO User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
PLUTO
USER GUIDE
manual v1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the PLUTO and is the answer not in the manual?

Questions and answers

Summary of Contents for ARTESIAN BUILDS PLUTO

  • Page 1 PLUTO USER GUIDE manual v1.0...

  • Page 3: Specification

    SPECIFICATION CASE OVERVIEW BOX CONTENTS ASSEMBLY APPENDIX A - STORAGE APPENDIX B - COOLING WARRANTY SUPPORT / CONTACT...
  • Page 4 Case dimensions: (LxWxH) 360 x 142 x 345 mm. Sata 2.5” drive positions: up to 10 Motherboard compatibility: Mini-ITX. Power supply type: SFX (recommended), SFX-L. Fans: 2 x 60 mm on rear panel. 1 x 120 mm on bottom panel (not compatible with 280 mm radiator). Fans are not included.
  • Page 6 Total internal length Width Internal Lenth of opening Width from case wall to side panel...
  • Page 7 1 - Wood panel 2 - Metal chassis 3 - Side brackets 4 - Wood base 5 - Aluminum side panel 6 - Aluminum side panel...
  • Page 8 1 x Case 1 x Case 10 x M3 screws 10 x M3 screws 8 x 6-32 screws 8 x 6-32 screws 2 x Thumb screws 2 x Thumb screws 1 x Riser cable 1 x Riser cable...
  • Page 9 1. Remove both side panels. 1. Remove both side panels.
  • Page 10 3. Prepare the motherboard. Install the CPU, 2. Remove the side brackets. RAM, NVME M2 drive and AIO backplate.
  • Page 11 4. Install the I/O shield. 5. Install the motherboard in the case and attach with 6-32 screws.
  • Page 12 7. Plug in the necessary cables into the PSU. 6. Install the PSU with the fan facing towards 24 pin motherbaord cable, 8 pin EPS cable, the venting holes. Secure it in place with 4 6-32 PCIE power cables. if installing SSDs, sata screws.
  • Page 13 8. Plug in the motherboard 24 pin and CPU EPS 9. Install pcie riser cable onto the deeper standoffs. Use M3 screws to lock it in place. 8 pin cables into the motherboard. Plug in the power button into the motherboard header. Bend the riser as shown in the image.
  • Page 14 10. Install the SSDs and lock them in place with M3 screws. Connect their power and data cables. Installing SSDs here will not allow for a 280 mm radiator or a bottom 120 mm fan. For 11. Install the radiator with fans. 240 mm radiator alternative mounting options, please reference shown on this image.
  • Page 15 12. Install the CPU block. Then wire up the AIO 13. Install GPU vertically into its cable and fans and pump block to power and appropriate secure with thumb screws. motherboard headers.
  • Page 16 14. Plug in PCIE power cables into the GPU. 15. Put the brackets back in the case (optional).
  • Page 17 Please check next pages (appendix A and B) for alternate storage and cooling options. 16. Re-attach the side panels and that’s it!
  • Page 18 You can attach SSDs on the side brackets. And You can attach SSDs on the side brackets. And the brackets can be fl ipped such that the SSDs the brackets can be fl ipped such that the SSDs are facing the outside. are facing the outside.
  • Page 19 Up to 10 SSDs can be installed if there is no radiator or bottom 120 mm fan. Installing SSDs in the bottom will not allow for the 120 mm fan.
  • Page 20 Two 60mm fans can be installed on the back of Two 60mm fans can be installed on the back of Two 60mm fans can be installed on the back of the case for added cooling potential. the case for added cooling potential. the case for added cooling potential.
  • Page 21 A 120 mm fan can be optionally installed in the A 120 mm fan can be optionally installed in the It fi ts a 280 mm radiator that is 316 mm x 154 mm bottom. This will confl ict with bottom mounted bottom.
  • Page 22 You can add a second radiator on the side brackets. The side brackets support either a 240 mm, or a 280 mm radiator as a second radiator. The second radiator must be a slim radiator (~30 mm thick). It will fi t with 25 mm thick standard 120 mm fans, but slim fans are recommended.
  • Page 23 Case with two 280 mm radiators installed. In this confi guration, the 280 mm radiator that is placed on the side brackets must have a max 240 mm radiators (30 mm thick) with 25 mm width of 144 mm. thick fans.
  • Page 24 Mounting the side radiator is a 3 step process. Mounting the side radiator is a 3 step process. Step 1: mount the radiator to the side brackets, Step 1: mount the radiator to the side brackets, pushing the brackets as close together as pushing the brackets as close together as possible.
  • Page 25 Step 2: place the radiator into the case and Step 2: place the radiator into the case and slide the brackets outwards underneath the slide the brackets outwards underneath the fl anges. Line up the mounting holes with the fl anges. Line up the mounting holes with the frame and secure the brackets.
  • Page 26 If the GPU is single slot with a waterblock, the If the GPU is single slot with a waterblock, the pcie riser cable can be relocated to move the pcie riser cable can be relocated to move the gpu closer to the side of the case. This will gpu closer to the side of the case.
  • Page 27 To relocate the gpu, use the other set of standoffs To relocate the gpu, use the other set of standoffs Total clearance with 1 slot GPU relocated is 90 mm. Total clearance with 1 slot GPU relocated is 90 mm. for the riser cable.
  • Page 28 When using an air cooler, you can replace the side When using an air cooler, you can replace the side panel radiator for two 120 mm fans or two 140 mm panel radiator for two 120 mm fans or two 140 mm Air coolers up to 110 mm can be installed.
  • Page 29 This product is guaranteed for thirty six (36) months from the date of delivery to the end- user, against defects in materials and/or workmanship. Within this limited warranty period, the product will either be repaired or replaced at Artesian’s discretion. Please note, wood is a living material and it is natural for some structural movement to occur over time in different humidity environments.
  • Page 30 If you have any questions, please contact us on our site: https://artesianbuilds.com/contact-us/...
  • Page 31 © Artesian Builds, All rights reserved. Artesian Builds, the Artesian Builds logotypes, product names and other specifi c elements are trademarks of Artesian Builds, registrered in United States. Other product and company names mentioned herein may be trademarks of their respecive companies. Contents and specifi cations as...
