SPOTT.U YMT-B21 User Manual

Weight bench
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
SPOTTU WEIGHT BENCH
Customer Service Email:
support@spott-u.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YMT-B21 and is the answer not in the manual?

Questions and answers

Summary of Contents for SPOTT.U YMT-B21

  • Page 1 USER MANUAL SPOTTU WEIGHT BENCH Customer Service Email: support@spott-u.com...

  • Page 2: Care And Maintenance

    Keep the bench on a solid surface, and keep a minimum of two feet (0.5m) from any walls or furniture. Make the area behind the bench completely clear during use. PRODUCT SPECIFICATION Product Name: SpottU Weight Bench Model Number: YMT-B21 Assembled Dimension: 64x26x18.3inch/162.5cm x 66cm x 46.5cm G.W./N.W.: 65.7/68.2LBS, 29.85/30.97KGS Maximum weight capacity: 1000 lbs.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS Ensure that your workout area is free of possible sources of danger. For example, packaging material that’s laying around and could be dangerous. There is always a risk of suffocation if children play with plastic bags. The unit is designed for use by adults. Children should not be allowed to play with it. Children at play behave unpredictably and dangerous situations may occur for which the manufacturer cannot be held liable.

  • Page 4: Parts List

    PARTS LIST Part Description Size Qty. Part Description Size Qty. Front Leg Bolt for Cushion M8x20 Rear Leg Cushion Pad Main Frame Plastic End Cap 30x60mm Base Frame Plastic End Cap 75mm Seat Tube Grip Cover Ø23x5x120 Seat Adjuster Plastic End Cap Ø25 Backrest Tube Plastic End Cap...
  • Page 5 PARTS ASSEMBLY DRAWING Wrench (provided) x2 Allen wrench (provided) x1 TOOL KIT...
  • Page 6 VIDEO ASSEMBLY INSTRUCTIONS For video instructions on how to assemble the SpottU weight bench you can go to spott-u.com/instructions on your computer or phone. http:// There is one video for each assembly step to make it easy and has- sle-free to assemble your SpottU weight bench. In this brochure you will find the instructions in text and image format in the following pages.

  • Page 7: Assembly Steps

    ASSEMBLY STEPS STEP 1: ASSEMBLING THE FRAME The following parts are needed in this step. MAIN FRAME BASE FRAME FRONT LEG (29) PLASTIC END CAPS (4 PCS) (12) WASHER Ø10 (4 PCS) (29) REAR LEG (11) BOLT M10X65 (4 PCS) (29) (12) (29)
  • Page 8 Rotate the Main Frame (3) with the Rear Leg (2) assembled in step B once again and place it on top of the Base Frame (4) and Front Leg (1) as shown in the illustration above. Insert the Plastic End Caps (29) for each leg (1) & (2). STEP 2: ASSEMBLING THE FRAME &...

  • Page 9: Seat Adjuster

    STEP 3: ASSEMBLING THE SEAT ADJUSTER AND SEAT -SEAT ADJUSTER The following parts are needed in this step. SEAT TUBE (1 PC) (24) CUSHION PAD (1 PC) (23) (16) BOLT M8X20 BOLT M10X85 (1 PC) (1 PC) (12) WASHER (2 PC) SEAT ADJUSTER (12) (1 PC)
  • Page 10 -SEAT The following parts are needed in this step. SEAT (1 PC) SEAT TUBE (1 PC) (19) (19) WASHER Ø8 (4 PCS) (18) (19) (18) BOLT M8X20 (4 PCS) (18) (19) (18) INSTRUCTIONS Flip the Seat Pad (9) upside down and place the Seat Tube (5) on the bottom part of the seat and align the screwing holes.
  • Page 11 STEP 4: ASSEMBLING THE BACKREST ADJUSTER AND HANDLES TO THE BACKREST TUBE -BACKREST TUBE AND HANDLES The following parts are needed in this step. (7) BACKREST TUBE (1 PC) (32) BOLT M10X160 (1 PC) (12) (28) (12) WASHER (2 PCS) (27) (15) NYLON NUT (1 PC) GRIP COVER...

  • Page 12: Backrest Cushion

    HANDLES Proceed to Slide the Handle (39) onto the dragonfly frame, attached to the Backrest Tube (7), and secure the Handles (39) with Bolts (40). Once the Handles (39) have been secured with the Bolts (40), proceed to install the Grip Covers (27) on top of the Handles (39).
  • Page 13 STEP 5: ASSEMBLING THE SEAT The following parts are needed in this step. SEAT (13) BOLT M10X100 (12) WASHER Ø10 (2 PCS) (12) (1 PC) (15) NYLON NUT M10 (1 PC) MAIN FRAME INSTRUCTIONS Place the Seat (9) onto the Main Frame (3), align the Main Frame (3) bolt holes to the holes of the two washers (14) attached to the Seat (9).
  • Page 14 STEP 6: ASSEMBLING THE BACKREST CUSHION ONTO THE MAIN FRAME The following parts are needed in this step. (13) BOLT M10X100 (1 PC) (12) WASHER Ø10 (2 PCS) (12) (15) NYLON NUT M10 (1 PC) WASHER Ø20XØ16XØ10 (2 PCS) MAIN FRAME INSTRUCTIONS Place the Backseat (10) onto the Main Frame (3).
  • Page 15 STEP 7: ASSEMBLING THE LEG HOLDER The following parts are needed in this step. (34) LEG HOLDER INNER TUBE WITH FOAM ROLLER (1 SET) (38) ELASTIC PIN (1 PC) (33) LEG HOLDER OUTER TUBE (1 PC) (37) LOCKING BOLT (1 PC) BASE FRAME (1 PC) INSTRUCTIONS...
  • Page 16 STEP 8: ATTACHING THE ELASTIC BANDS -VELCRO STRIPES Lay the stripe flat and slide under the back leg. Wrap the stripe around the leg and insert the stripe through the metal ring.
  • Page 17 Tighten the stripe as much as possible Apply pressure on the velcro in once threaded through the metal ring. order to complete the process. -ELASTIC BANDS Attach your elastic bands to the metal ring.
  • Page 18 Customer Service Email: support@spott-u.com For video instructions on how to assemble the SpottU weight bench you can go to spott-u.com/ instructions on your computer or phone. Full instructions in this manual.
