Summary of Contents for Atreum Lighting HYDRA Series
- Page 1 HYDRA GROW LIGHT USER MANUAL For video setup instructions, scan the QR code or visit atreumlighting.com...
- Page 2 4. The unit has been dropped, or its enclosure or chassis is damaged GENERAL CARE Atreum Lighting HYDRA Series systems are passively cooled with zero moving components. They are designed for years of maintenance-free performance. Some basic care will keep your system operating at peak performance cycle-after-cycle.
- Page 3 SPECIFICATIONS Model Input Power Input Voltage (AC) Amps HYDRA-1000 100W±5% 100-305VAC 0.84A @ 120V 0.48A @ 208V 0.42A @ 240V 0.37A @ 277V DIMENSIONS & WEIGHT Model Weight Dimensions HYDRA-1000 1.95kg (4.3lbs) 300mm x 300mm x 61mm 11.8in x 11.8in x 2.4in SYSTEM HARDWARE &...
- Page 4 ASSEMBLY INSTRUCTIONS Unbox stainless steel hanger kits. Attach the adjustable rope hangers. Attach 4 small hooks to the 4 corner Hang the light above the plants at holes on the back side of the light. appropriate height. Plug the power cord into the control box. Plug the power cord into the wall socket.
- Page 5 RECOMMENDED HANGING HEIGHT Hang at 24” Hang at 18” - 24” Hang at 12” - 18” SEEDING FLOWERING FUNCTION OVERVIEW Power Readout On/o Switch Dimming Knob (10%-100%) Dimming Signal Input Dimmer Signal Output Dimmer Lead/Follow Switch...
- Page 6 SINGLE LIGHT DIMMING OPERATION 1. Turn on light switch OFF ON 2. Set dimmer switch to Lead LEAD FOLLOW 3. Adjust light using Dimming Knob...
- Page 7 MULTI-LIGHT DIMMING OPERATION Connect multiple lights using the RJ11 cable, from the DIM Output of one unit to the DIM Input of the next unit. INPUT OUTPUT INPUT OUTPUT INPUT OUTPUT INPUT OUTPUT Set one light as the primary by switching the dimmer switch to LEAD. Set all subsequent lights to FOLLOW.
- Page 8 Review our products, share your grow, and stay update-to-date on Atreum Lighting news and products. atreumlighting.com...
