RADIO

MANUAL

MODEL: 1000-RIO160U

Table of Contents

Need help?

Do you have a question about the 1000-RIO160U and is the answer not in the manual?

Questions and answers

Summary of Contents for Road Choice 1000-RIO160U

Page 1 RADIO MANUAL MODEL: 1000-RIO160U...
Page 2 ACCESSORIES PAGE 2 Remote Control Unit Mounting Collar Trim Plate Power Connector (Battery Included) QTY: 1 QTY: 1 QTY: 1 QTY: 1 (FX0214C384ZB) (YFC054C079YA) (YAJ024C146CA) (YFX994C199CA) Operating Installation Mounting Bolt Lock Cancel Plate Rubber Bushing Instructions Instructions (5 mm ø) Installation Kit Instruction Kit QTY: 1 Set...
Page 3: Safety Information
SAFETY INFORMATION PAGE 3 Read the operating instructions for the unit and all other components of your car audio system carefully before using the system. They contain instructions about how to use the system in a safe and effective manner. Panasonic assumes no responsibility for any problems resulting from failure to observe the instructions given in this manual.
Page 4 SAFETY INFORMATION PAGE 4 Observe the following warnings when installing. Disconnect the lead from the negative (–) battery terminal before installation. Wiring and installation with the negative (–) battery terminal connected may cause electrical shock and injury due to a short circuit. Some cars equipped with the electrical safety system have specific procedures of battery terminal disconnection.
Page 5 SAFETY INFORMATION PAGE 5 Observe the following cautions when installing. Refer wiring and installation to qualified service personnel. Installation of this unit requires special skills and experience. For maximum safety, have it installed by your dealer. Panasonic is not liable for any problems resulting from your own installation of the unit.
Page 6: Before Reading These Instructions
BEFORE READING THESE INSTRUCTIONS PAGE 6 Panasonic welcomes you to our constantly growing family of electronic products owners. We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully selected components, and assembled by people who are proud of the reputation their work has built for our company.
Page 7: Disc Cleaning
NOTES ON DISCS PAGE 7 HOW TO HOLD THE DISC DISC INSERT The surfaces of new discs tend to be slippery. Do not touch the underside of the disc. Therefore, when using such a disc for the first Do not scratch the disc. time, it may not load satisfactorily even when it has been inserted into the unit.
Page 8: Remote Control Unit
REMOTE CONTROL UNIT PAGE 8 This instruction manual explains operations for use with the buttons on the main unit. (Different operations excluded.) When using the remote control unit, aim the remote control unit at the remote sensor and operate it. POWER TOGGLES POWER ON/OFF VOLUME...
Page 9: First Time Power On
PREPARATION PAGE 9 FIRST TIME POWER ON BATTERY INSTALLATION 1. Set your car’s ignition switch to the ACC or Pull the insulation film out from the backside of ON position. the remote control unit gently. 2. Press [SRC] (PWR: Power). CLOCK SETTING CLOCK DISPLAY AT POWER OFF The 12-hour (AM/PM) system is used for the...
Page 10: Power On/Off
GENERAL PAGE 10 CAUTION: Set the volume level to low enough before the AUX connection is completed. Failure to observe this may generate loud noise and accordingly damage your speakers and your hearing. SOURCE REMOTE CONTROL SELECTS A SOURCE SENSOR POWER TOGGLES POWER ON/OFF...
Page 11 RADIO (AM/FM) PAGE 11 CAUTION: To ensure safety, never attempt to preset stations while you are driving. SOURCE FILE SELECTS A SOURCE DECREASES/INCREASES THE FREQUENCY (FOR SEEK TUNING, HOLD IT DOWN FOR MORE THAN 0.5 SECONDS AND DISPLAY RELEASE IT) SWITCHES THE INFORMATION ON THE DISPLAY...
Page 12: Disc Player
DISC PLAYER PAGE 12 DISC SLOT TAKES A DISC IN WITH THE FILE PRINTED SIDE FACING UP SKIP TO THE PREVIOUS/NEXT TRACK/FILE IN THE PLAYER MODE. FOR FAST REVERSE/ FAST FORWARD, HOLD DOWN EITHER OF THEM. SOURCE SELECTS A SOURCE EJECT EJECTS THE DISC DISPLAY...
Page 13: Random Play
DISC PLAYER PAGE 13 DISPLAY CHANGE RANDOM PLAY Press [DISP]. All the available songs (tracks/files) are played in a random sequence. Disc Player (CD-DA Disc): Press [4] (RANDOM). lights. Press again to TRACK / PLAY TIME cancel. DISC TITLE FOLDER RANDOM PLAY (MP3) TRACK TITLE All the available files in the current folder are played in a random sequence.
Page 14: Audio Settings
AUDIO SETTINGS PAGE 14 VOLUME SELECTS A VALUE IN THE AUDIO MENU PUSH SELECT SELECTS ITEMS IN THE AUDIO MENU 1. PRESS [VOL] (PUSH SELECT) TO OPEN THE AUDIO MENU NOTE: If no operation takes place for more than 5 seconds in audio setting (2 seconds in the volume adjustment), the display returns to the regular mode.
Page 15: Troubleshooting
TROUBLESHOOTING PAGE 15 If you suspect something wrong, Check and take steps as described below. If the described suggestions do not solve the problem, it is recommended to take the unit to your nearest authorized Panasonic Service Center. The product should be serviced only by qualified personnel. Please refer the checking and the repair to professionals.
Page 16 SPECIFICATIONS PAGE 16 GENERAL POWER SUPPLY ............12 V DC (11 V – 16 V) test voltage; 14.4 V, negative ground ............Less than 2.2 A (CD mode, 0.5 W x 4 channels) CURRENT CONSUMPTION ........50 W x 4 channels (at 1 kHz), volume control maximum MAXIMUM POWER OUTPUT TONE ADJUSTMENT RATE ...............................
