Summary of Contents for MICRO-LAM u-lam
- Page 1 -LAM, Inc. LASER CONTROL STATION MANUAL ICRO Cutting Edge Precision. Laser Focused. Micro-LAM, Inc. 5960 S Sprinkle Rd., Portage, MI 49002, USA +1 (269) 288 4100 www.micro-lam.com...
- Page 2 Laser Safety & Control Station Touchscreen Touchscreen Laser Controls BATCoM HALO Laser Control Station – Suggested Layout...
-
Page 3: Laser Safety
Laser Safety Laser Barriers *Setup may vary from one machine to another Laser Barrier: Suggested Layout Door Magnets Mount on Moving Surface Mount on Fixed Surface 6 Door magnets provided standard. Mount on top of machine using double sided tape or fasteners Caution: Do not mount the wired side of the magnet on a moving surface. - Page 4 To Door Magnet Connectors on Cart Suggested Locations for Door Magnets Door Magnet Jumper Door magnet jumper(s) will need to be used if fewer than 6 door magnets are installed. Lathe E-Stop & M Code Integration A qualified technician will perform integration of M-Code and E-stop statuses from the lathe to the control station.
- Page 5 Laser Status Lights READY DOOR OPEN LASER ON LASER OFF LASER OFF – Laser is ON – LASER ON AT COMMANDED POWER OUTPUT BLUE – Laser is OFF – READY FOR OPERATION & ALL INTERLOCKS SATISFIED VIOLET – Laser is OFF – DOOR INTERLOCK(S) NOT SATISFIED Laser Control Station Mobility The laser control station has been designed with portability in mind.
- Page 6 Display Functionality Welcome Screen – Tap Anywhere to Skip to Toggle Screen Alignment Overview – Tap Anywhere to Toggle Screen...
- Page 7 Guide Laser Status & Laser Toggle Button Beam (Disabled when M-Code Active) Toggle Switch % Power Adjustments (Default ±5%) Toggle Screen (Min – 10%) (Outlined Red) Laser Status Screen – Always Active when Laser is ON The Laser Toggle Button is also disabled when the machine M-Code command is active to prevent accidental laser closure.
- Page 8 Laser Control Station Master Settings Page Click the top left corner to access the master settings page Click LOGIN – The default factory password is set to 526 Click NEXT...
- Page 9 Power Increment Levels – Default increment/decrement value can be set to 1, 2 or 3 M-20 Bypass – If active, lathe MCode will have no effect on emission ON/OFF Output Power Limit – Emissions have been restricted to 24% by default. Change with caution! Emission Automatic Shutdown Delay Time - Default set to 100 mins.
- Page 10 Electrical Maintenance Procedures To troubleshoot any electrical integration, the electrical compartment may be accessed by lifting the top panel off of the control station. (To be performed by qualified personnel only.) Remove the 4 M6 screws that secure the monitor before removing the top panel. Remove the 5/16-32 socket head caps screws that secure the top panel.
- Page 11 Caution: Once the top panel is removed, the Ethernet wire, and the power cord to the touchscreen display must be removed before top panel can be separated from the laser control station. WARNING The provided laser barriers are certified OD 6+ 1064nm. Do not remove them when the laser is in operation.
