Summary of Contents for Topicon MDT540
- Page 1 Mobile Data Terminal MDT540 Quick Start Guide Rev.1...
- Page 2 Introduction MDT540 is a mobile data terminal device based on Android operating system with 5-inch capacitive touch screen and rugged design. Features • Android 7.0 Operating System • 5.0-inch TFT LCD 800*480 pixels Screen with Capacitive Touch • GNSS Receiver •...
- Page 3 Getting Started SIM CARD & MICRO SD CARD 1/ Unscrew the protective covers. 2/ Insert the SIM card with the gold contacts facing up. 3/ Insert the microSD card with gold contacts facing up. 4/ Push the card in the direction of the arrow as shown in the figure.
- Page 4 Safety Notices & Warnings ● Do not use and/or leave the device in high or low temperature and potentially explosive environments to prevent permanent damage. ● Wipe or dry the LCD screen of the device using a soft cloth. Do not use any liquid cleaners.
- Page 5 The SAR limit of USA (FCC) is 1.6 W/kg averaged. Device types: portable device (FCC ID: 2AHAF-MDT540) has also been tested against this SAR limit. SAR information on this and other pad can be viewed on‐line at http://www.fcc.gov/oet/ea/fccid/.
- Page 6 The SAR limit of IC is 1.6 W/kg averaged. Device: GPS (IC: 21087-MDT540) has also been tested against this SAR limit. This device was tested simulation typical 0 mm to body. To...
