Installation and Instruction Manual
WIFI LED Panel Light QS- PLT595X595- 36W-230V-TUNE-WIFI
1. Technical Specifications
Product type
Input Voltage
Input Current
Load
Operation frequency
Color
IP rating
Insulation
Other Protocol
Test standards
2.Main Features
1.
Work with Amazon Alexa/ Echo Dot& Google home& IFTT
2.Adjust your lights via your mobile phone or Voice Control.
3.Short-circuit Protection,Over-voltage Protection and Over-temperature Protection
4.
3 .
Installation
Warnings:
1. Installation must be carried out by a qualified
engineer in accordance with local regulations.
2. Disconnect power supply before installing.
3. Ensure environmental conditions are suitable
for electronic equipment.
4.Keep the device out of reach of children.
WIFI LED Panel Light
220-240VAC 50Hz
250mA
36W
2.4 GHz - 2.483 GHz
CCT 3000K-6000K adjustable
IP20
Class II
Bluetooth
EN301489 EN62311 EN55015
EN61547 EN60669 IEC60669
T.
Product Size
Aihomestyle
595mm
595mm
mm
Advertisement
Table of Contents
Summary of Contents for Aihomestyle QS-PLT595X595
- Page 1 Installation and Instruction Manual Aihomestyle WIFI LED Panel Light QS- PLT595X595- 36W-230V-TUNE-WIFI 1. Technical Specifications Product type WIFI LED Panel Light Input Voltage 220-240VAC 50Hz Input Current 250mA Load Operation frequency 2.4 GHz - 2.483 GHz CCT 3000K-6000K adjustable Color...
- Page 2 5.Do NOT clean with liquid. 6.Keep the device away from water,damp or hot environment. 7.Do NOT exceed the recommended electrical ratings. 8.Install the device away from strong signal sources such as microwave oven that may cause to signal intertuption resulted to abnormal operation of the device. 9.Obstruction by concrete wall or metallic materials may reduce the effective operation range of the device and should be avoided.
- Page 3 Add Device Cancel Add manually Search Device Electrical Smart Lighting Lighting Lighting Devices Devices Home (bluetooth) Appliance... kitchen Security Lighting & Sensor Devices (ZigBee) sport Switch the on/off button for 5 times until & Health Open the App,select "+"on the top right of the home then the light connected to the driver page to add device.At the net-pairing,select the type ready for pairing.
