- Page 1 ESY 1~ User Manual Specialized Vac stepless Controllers single-phase Asynchronous Motors on Axial & Centrifugal Fans Ventilated Heat Exchangers Drycoolers & Air Cooled Condensers YEAR FAN speed Control Solutions...
-
Page 2: Precautions
WARNING ! HIGH LEAKAGE CURRENT First connect to Earth ! DO NOT touch the electrical parts of the circuit when the power supply is connected under any circumstances Safety Warnings • We disclaim all responsibility for accident, loss or damage caused by the use of these appliances. These must be correctly installed by qualified personnel in conformity with their intended use and, whenever needed, must undergo correct maintenance which should be carried out while ensuring the safety of people, domestic animals and goods. -
Page 3: Table Of Contents
ELECTRICAL CONNECTIONS ......................Errore. Il segnalibro non è definito. 5.1. Power Supply Connection (Terminal Block M1) ............................7 SIGNAL CONNECTIONS for the 4 CONFIGURATIONS (ALL-in-ONE) ....................8 6.1. OM CONFIGURATION (STANDARD SELPRO) ............................8 6.2. OX Configuration (on request) ..................................8 6.3. OV Configuration (on request) ..................................9 6.4. -
Page 4: Ec Directives & Technical Standards
EC DIRECTIVES & TECHNICAL STANDARDS This series has been designed and manufactured for use in industrial environments, and complies therefore with the following European Directives: • Machine Directive 98/37 CE and following amendments • Low Voltage Directive (LVD) 2006/95/EC • EMC Directive 2004/108/EC Thanks to its advanced technical solutions, the ESY100 series has obtained the CE mark in compliance with the EMC (Electromagnetic Compatibility) directive 2004/108/EC also in household environment. -
Page 5: Operating Modes And Applications
3. OPERATING MODES AND APPLICATIONS The ESY1 devices are electronic analog regulators of single-phase AC voltage, which use the phase-cutting principle (Triac) in order to vary the output active voltage applied to a resistive or inductive load. When connected to asynchronous high-slip electric motors of fans or pumps, they control their rotational speed in order to maintain the key parameter within desired values. -
Page 6: Technical Characteristics Esy-1
4. TECHNICAL CHARACTERISTICS ESY-1 Voltage 230V ± 10 % single phase – (on request 110V - 400V Frequency 50Hz standard (60 Hz only factory calibration) OWER UPPLY Overvoltage Protection for installation Category II (4 KV) Electronic analog regulators of single-phase AC voltage, which use the phase-cutting principle (Triac) in order to vary the PERATING output active voltage applied to a resistive or inductive load. - Page 7 Transducer voltage supply 22V (+10/-20%) max. 25mA Transducer voltage supply 22V (+10/-20%) max. 25mA Config. + 10V Transducer voltage supply 10,0V (±1%) Output signal for slave unit: 0-10Vdc or PWM (MAX 5 modules) Transducer voltage supply 22V (+10/-20%) max. 25mA Transducer voltage supply 22V (+10/-20%) max.
-
Page 8: Electrical Connections
5. ELECTRICAL CONNECTIONS Connect the controller as shown in the figure below, paying attention to the following points 5.1. Power Supply Connection (Terminal Block M1) -Before supplying power to the unit, check carefully the power connection and the efficiency of EARTH connection. -Ensure that power conductors and EARTH CABLES have a cross section suitable to the connected load. -
Page 9: Signal Connections For The 4 Configurations (All-In-One)
- SLAVE, using the input In4 ( for 0-10V control signal) The controllers of the ESY-1/ALL-in-ONE series can be set in the following four (4) configurations, described below. The OM configuration is standard SELPRO 6.1. OM CONFIGURATION (STANDARD SELPRO) N°... -
Page 10: Ov Configuration (On Request)
6.3. OV Configuration (on request) N° Name Function CONF. Output voltage supply + 5,0V ±1% Transducer Input 0-5 Vdc N° 1 Ground Transducer Input 0-5 Vdc N° 2 Output voltage supply + 5,0V ±1% Transducer Input NTC 10kohm N° 3 @ 25°C Ground Input N°... -
Page 11: Electrical Connection For Slave Module/S
7. Electrical connection for Slave Module/s The controllers of the ESY-1 / ALL-in-ONE series include moreover the SLAVE-ONE power units, in the two following versions: SLAVE-SV with input for 0-10Vdc control signal SLAVE-SP with input for PWM control signal All the models of the series share the same technical characteristics and are available in different sizes: 8 A –... -
Page 12: Connection Of Slave Modules, Sp Series (Pwm Power Units)
7.3. Connection of SLAVE modules, SP series (PWM power units) The SLAVE-SP unit allows the connection of the only PWM (PPM-Triac) control signal. The input is optimized in order to be compatible with every device having a PWM control signal, from 5V to 30V. All connected SLAVE-SP units require the same supply phase as the remote controller, which generates the PWM control signal (network synchronization) SLAVE –... -
Page 13: Esy-1: Control & Power Card In Detail, All-In-One Version
8. ESY-1: CONTROL & POWER CARD IN DETAIL, ALL-in-ONE version Led Led Led Led MAX OUT SPadj CUT-OFF (MIN OUT ) SP1adj SP2adj Double Set-Point optional card Jumper Description ESY-1 / ALL-in-ONE & LED DIRECT-REVERSE mode selection VAC Output at SET-POINT CUT-OFF / MIN OUT selection EXTRA-power control Output Power supply O.K. -
Page 14: Led Signals
LED signals 8.2. The cards present LED signals, which point out the state and the operation of the controller. The LED signals of the complete version ESY-1 / ALL-in-ONE are shown in the table below: 230Vac Green LED Power supply O.K. Green LED SP higher than the signal value 100%... -
Page 15: Set-Up Of Operating Limits And Parameters
9. Set-up of operating LIMITS and PARAMETERS 9.1. Available regulations in the standard ESY-1 version (ALL-in-ONE) The ESY-1 controllers present two regulation Trimmers for setting up the operating limits (MIN out / Cut-Off and MAX out), the automatic regulation performs the variations of fans speed, and a couple of 13-positions rotary switches for setting up the SET-Point of reference with ease. -
Page 16: How To Set Up The Operating Limits For Slave-One Modules (Only Slave-Sv Version)
9.3. How to set up the operating limits for SLAVE-ONE modules (only SLAVE-SV version) The following procedures allow to set up the AC voltage limits, within which the 0-10 Vdc control signal is automatically controlled. It allows to set up manually the minimum AC output voltage MIN Vac supplied to the fan, from 20% to 90%, and permits to check: - the correct phase-cutting of the controller... -
Page 17: Tables For The Set-Point Selection
After selecting the operating modes and setting up the operating limits, it is necessary to determine the operating point of the regulation: the SET-POINT, on the basis of the scales and ranges referring to the connected sensor (*). The Set-Point is easily and quickly fixed through the couple of 13-position rotary switches, named as follows: SP (main reference point for the regulation) and SPadj. -
Page 18: Set Point Values, Range 0-25 Bar (Transducer 4-20 Ma)
12,74 12,83 12,93 13,02 13,11 13,21 13,30 13,40 13,49 13,58 13,68 12,69 13,73 13,16 13,21 13,30 13,40 13,49 13,58 13,68 13,77 13,87 13,96 14,05 14,15 14,20 9.5.3. Set Point values, range 0-25 bar (Transducer 4-20 mA) 0-25 bar adj. adj. 4,69 4,77 4,93... -
Page 19: Set-Point Values, Range 0-45 Bar (Transducer 4-20 Ma)
9.5.5. Set-Point values, range 0-45 bar (Transducer 4-20 mA) 0-45 bar adj. adj. 8,45 8,59 8,87 9,15 9,43 9,72 10,00 10,28 10,56 10,85 11,13 11,41 11,55 10,00 10,28 10,56 10,85 11,13 11,41 11,69 11,97 12,26 12,54 12,82 9,86 12,96 12,82 13,10 13,38 13,67... -
Page 20: Set-Point Values, Range 10°C To 60°C (Ntc Probe 10Kohm@25°C)
9.5.7. Set-Point values, range 10°C to 60°C (NTC probe 10kohm@25°C) 10-60 °C adj. adj. 2,00 2,50 3,00 3,50 4,00 4,50 5,50 6,00 6,50 7,00 7,50 8,00 7,50 8,00 8,50 9,00 9,50 10,50 11,00 11,50 12,00 12,50 7,00 13,00 12,50 13,00 13,50 14,00 14,50... -
Page 21: Function Diagrams & Operating Parameters In Master & Slave Modes
10. Function diagrams & Operating parameters in MASTER & SLAVE modes Standard values of the proportional band (Pb): transducer 4-20 mA Pb=2.5 mA, transducer 0-5 Vdc Pb=0,65 Vdc, sensor NTC 10kohm@25°C Pb=7.0°C Min= Off= Vac= =fans maximum rpm - fans minimum rpm - fans off - voltage supply to the load;... -
Page 22: Accessories
11. ACCESSORIES 11.1. Manual Remote Control Units ♦ Series of potentiometers for manual remote control Potentiometer for external remote control Manual speed setting with 0-10 Vdc Available 1 & 10 turn versions, with standard knob ∅ ∅ ∅ ∅ 22 and silk screen label Available 10 turn version, with knob ∅... -
Page 23: Pressure Transducer For 4-20 Ma & 0-5 V
11.2 Pressure Transducer for 4-20 mA & 0-5 V Description 4-20 mA 0-5 Vdc Control signal 4 … 20 mA 0,5 … 4,5 V Power supply 8 … 28 V 5 V +/- 0,25V Range (bar) 0 … 15/25/30/45 0 … 30/45 Linearity <... - Page 24 TECHNICAL ASSISTANCE FORM 1. All ESY-1 equipments are guaranteed for 36 months from the date of testing. 2. The guarantee will be rendered invalid under these circumstances: • evidence of tampering with the mechanical or electrical parts • improper use •...
- Page 25 Via P. G. Piamarta, 5/11 Tel. (+39) 030.6821611 info@selproweb.com 25021 Bagnolo Mella (Bs) Fax (+39) 030.622274 www.selproweb.com User Manual ESY-1 / rev. 9 15.01.2008 www.selproweb.com...
