- Page 1 A m e r i c a n Towel Rack American Towel Rack Electric Towel Warmers Installation Instructions READ THESE INSTRUCTIONS CAREFULLY. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE IPX5 Rated...
-
Page 2: Protective Earth (Ground)
Safety Instructions: The following symbols relied up on for safety are used throughout this document. WARNING/CAUTION An appropriate safety instruction should be followed or caution to a potential hazard exists. PROTECTIVE EARTH (GROUND) To identify any terminal which is intended for connection to an external conductor for protection against electric shock in case of a fault, or the terminal of a protective earth (ground) electrode. -
Page 3: Safety Information
SAFETY INFORMATION - These products are intended for indoor use only. - This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. -
Page 4: Electrical Installation
ELECTRICAL INSTALLATION CAUTION: To provide continued protection against risk of electric shock, connect to properly grounded outlets only. Ensure that all electrical connections are made in accordance with local and national electrical codes. - All towel warmers contain a factory – filled water/glycol mixture - Means of disconnection from the electrical supply must be incorporated in the fixed wiring, isolating the towel rail from the supply by opening all live and neutral connections. - Page 5 2. Permanently Connected models CAUTION: To provide continued protection against risk of electric shock, connect to properly grounded outlets only. An optional hardwire cover kit may have been supplied with the electric towel warmer. Permanent connection of the towel warmer must be carried out by a suitably qualified person. Ensure that all electrical connections are made in accordance with local and national electrical codes.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS This product must be electrically installed in accordance with local regional electrical codes by a quali- fied engineer. Before attempting installation or servicing, turn off the electricity supply. Your Towel Rail shall be provided with either a NEMA 5-15P cordset or provision made for a permanent connection type installation. - Page 7 Fitting Index Apollo Page 8 Edwardian Page 10 Hercules Page 12 Manhattan Page 14 Premier Straight Page 16 Premier Curved Page 18 Page 20 Quebis Straight Quebis Curved Page 22 Page 24 Saber Taurus Columbine Page 26...
-
Page 8: Hardwire Kit
Apollo 3.34 Length 2.75 Fixing Centre L 3.14 2.75 3.14 4.52 2.63 2.75 Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.16 1.00 4.64... -
Page 9: Installation
Installation: 1) Wall Plug 2) Wall Support 3) Grub Screw 4) Allen Key (Not Supplied) 5) Wall Screw 6) Solid Fixing Lug Apollo Weight Fixing Centres (H) Fixing Centres (L) Height (”) Length (”) (lbs) +/- 0.07” +/- 0.07” RXAP-1050500-CH 21.60 35.43 18.30... - Page 10 Edwardian 4.48 Length Fixing Centre L 0.66 0.66 3.50 Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.16 1.00 4.64 2.75 3.26 1.37 4.92...
- Page 11 Installation: 1) Screw 2) Floor Mount 3) Hex Screw 4) Plug 1) Grub Screw 2) Allen Key (Not Supplied) 3) Screw 4) Wall Support 5) Wall Plug Step 1: points must be securely attached to a stud or masonry. It is recommended that this unit is installed into Drywall Only.
- Page 12 Hercules Length 3.62 Fixing Centre L 2.67 2.67 4.52 2.75 Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.16 1.00 4.64 2.75 3.26 1.37...
- Page 13 Hercules Weight Fixing Centres (H) Fixing Centres (L) Height (”) Length (”) (lbs) +/- 0.07” +/- 0.07” RXHE-0800542 31.3 26.14 19.68 31.49 21.33 RXHE-1200542 45.8 41.49 19.68 47.24 21.33 RXHE-1500542 59.1 53.77 19.68 59.05 21.33 RXHE-0800642 35.4 26.14 23.62 31.49 25.27 RXHE-1200642 51.6...
- Page 14 Manhattan Length Length Length 4.33 Fixing Fixing Centre L Fixing Centre L Centre L 3.74 16.73 1.37 3.14 4.52 4.52 4.52 2.75 2.75 2.75 Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.10 4.52 2.75...
- Page 15 Installation: 1) Wall Plug 2) Wall Support 3) Grub Screw 4) Allen Key (Not Supplied) 5) Wall Screw 6) Solid Fixing Lug Manhattan Weight Fixing Centres (H) Fixing Centres (L) Fixing Centres (L) Height (”) Length (”) (lbs) +/- 0.07” TOP +/- 0.07”...
- Page 16 Premier Straight Length Fixing Centre L 3.14-3.93 3.28 3. 28 4.52 2.36-3.14 2.75 Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.16 1.00 4.64...
- Page 17 Installation: Step 1: Select the desired mounting position, make sure the wall 1) Front Cover Cap 5) Bracket Wall Support 2) Bracket Assembly 6) Bracket Securing Screw points must be securely attached to a stud or masonry. It is 3) Bracket Securing Part 7) Wall Screw recommended that this unit is installed into Drywall Only.
- Page 18 Premier Curved 3.38-4.17 Length Fixing Centre L 3.28 - All the dimensions are shown in inches - Tube dia 0.78” - Header tube dia 1.18” x 1.18“ - Bracket length – 2.16” to 2.95“ - ½ inch BSP bottom opposite end connections 3.28 - Test pressure: 10 Bar - Max working temperature: 8 Bar...
- Page 19 Installation: Step 1: Select the desired mounting position, make sure the wall 1) Front Cover Cap 5) Bracket Wall Support is adequate to take the fixing points of the rail i.e anchor 2) Bracket Assembly 6) Bracket Securing Screw points must be securely attached to a stud or masonry. It is 3) Bracket Securing Part 7) Wall Screw recommended that this unit is installed into Drywall Only.
- Page 20 Quebis Straight Length 3.14 Fixing Centre L 3.14 3.14 2.55 4.52 2.75 Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.10 4.52 2.75 3.28...
- Page 21 Installation: 1) Wall Plug 2) Wall Support 3) Grub Screw 4) Allen Key (Not Supplied) 5) Wall Screw 6) Solid Fixing Lug Quebis Straight Weight Fixing Centres (H) Fixing Centres (L) Height (”) Length (”) (lbs) +/- 0.07” +/- 0.07” RXQU-1100600 26.23 37.00...
- Page 22 Quebis Curved Length 4.52 (19.68) - 5.11 (23.62) Fixing Centre L 3.14 3.14 2.67 4.52 2.75 4.52 (19.68) - 5.11 (23.62) Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.10 4.52 2.75...
- Page 23 Installation: 1) Wall Plug 2) Wall Support 3) Grub Screw 4) Allen Key (Not Supplied) 5) Wall Screw 6) Solid Fixing Lug Quebis Curved Weight Fixing Centres (H) Fixing Centres (L) Height (”) Length (”) (lbs) +/- 0.07” +/- 0.07” RXQC-1100600 25.17 37.20...
- Page 24 Saber Lengt 4.72 Fixing Centre L 5.51 Lengt 1.77 Fixing Centre L 2.36 1.18 2.36 4.52 1.18 2.75 2.55 RXSB-1000500-BL RXSB-1800570-BL Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.10 4.52 2.75...
- Page 25 - All the dimensions are shown in inches - Header tube dia 1.57” x 1.18“ - Bracket length – 1.96” - ½ inch BSP bottom opposite end connections - Test pressure: 10 Bar - Max working temperature: 8 Bar - Heat output – in accordance with EN 442 Please Note: Hydronic units only - Please allow minimum of 3.93”...
- Page 26 Taurus Columbine 9.05 3.62 Length 0.66 Fixing Centre L Summer Element for 26.18” Tapping Centres only Return Flow Hardwire Kit Caution: All electrical installations are be done by a Licensed Electrician It is the installers responsibility to follow all Local By-Laws, Regulations and Electrical Codes 1.16 1.00 4.64...
- Page 27 Taurus Columbine Weight Fixing Centres (H) Fixing Centres (L) Height (”) Length (”) (lbs) +/- 0.07” +/- 0.07” RXTA-0960665-CH 16.53 36.51 23.62 37.79 26.18 Installation: 1) Screw 2) Floor Mount 3) Hex Screw 4) Plug 1) Grub Screw 2) Allen Key (Not Supplied) 3) Screw 4) Wall Support...
- Page 28 A m e r i c a n Towel Rack...
