Avaya one-X

The phone supports 24 programmable call appearance/feature buttons. The labels for these are displayed in the main display,

and can be controlled by the adjacent buttons.

Making a Call

1. If you are not already on a call, just dial the number, speaker will automatically activate and the first available call

appearance button is used for the call. Alternatively, press a specific appearance button in order to make a call using

that button.

2. For outside calls, dial "9" or given access code to reach an outside line from any of the call appearances buttons.

3. You can now begin your conversation.

To call an extension directly over the speakerphone, press Intercom (located on the 2

the extension number and press the Call soft key.

Note: If person you attempt to call is in a "busy" state the phone will ring to you then cover to voicemail if not answered.

1. When you receive a call, a ring tone and a "slow flashing green lamp" on an appearance button indicates an alerting

call.

2. If you are active on a call, place the active call on hold by pressing the Hold soft key and press the appropriate call

appearance.

3. To retrieve a call placed on hold, press the call appearance button with the "fast flashing green lamp".

Note: calls placed on hold can only be picked up on that extension.

4. To send an incoming call immediately to voice mail, press the Drop or To VM soft key. To quiet an incoming call, press

the Ignore soft key and this will stop the phone from ringing.

1. Answer or place a call via the call appearance buttons.

2. Press one of the unlit "Park" buttons (e.g. "Park 1", "Park 2" or "Park 3").

95xx/96xx Series Telephone

page of options) then enter in

Table of Contents

Do you have a question about the Avaya one-X 95 Series and is the answer not in the manual?

Page 1 ® Avaya one-X 95xx/96xx Series Telephone The phone supports 24 programmable call appearance/feature buttons. The labels for these are displayed in the main display, and can be controlled by the adjacent buttons. Making a Call 1. If you are not already on a call, just dial the number, speaker will automatically activate and the first available call appearance button is used for the call.
Page 2 Answering a Parked Call 1. Press the appropriate “Park” button (e.g. “Park 1”, “Park 2”) with the “slow flashing red lamp”, then press the connect soft key. You will now have control of the call. Transferring a Call 1. Answer call by either lifting handset or pressing your speaker button. 2.
Page 3 6. For details of the conference call press the Details soft key. · To scroll through the list of callers in the conference, use the Up and Down arrow keys. · To drop a caller from the conference, highlight them and press Drop. ·...
Page 4 9504 9508/9608...
