Operating Manual

Scrubbing Unit TSW 2

Mounting

Operating

Maintenance

Trilety G.m.b.H.

Schwarzbergweg 19

A-5400 Hallein

Telefon: +43 6245 83 40 10

Fax: +43 6245 83 40 132

verkauf@trilety.at

www.trilety.at

*= special equipment

. 1

Table of Contents

Need help?

Do you have a question about the TSW 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for TRILETY TSW 2

Page 1 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Operating Manual Scrubbing Unit TSW 2 Mounting Operating Maintenance Trilety G.m.b.H. Schwarzbergweg 19 A-5400 Hallein Telefon: +43 6245 83 40 10 Fax: +43 6245 83 40 132 verkauf@trilety.at www.trilety.at *= special equipment...
Page 2: Table Of Contents
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Table of Contents Measurements and weight ...................... 3 Safety Instructions ...................... 4 Mounting Scrubbing Unit .................... 5 Demounting Scrubbing Unit ..................9 Operation in Scrubbing Mode ................... 10 Operation Panel ........................10 Start scrubbing ........................10 Use waste water system ......................
Page 3: Measurements And Weight
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Measurements and weight Weight without suction channel and suction hoses approx.254kg *= special equipment...
Page 4: Safety Instructions
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Safety Instructions The sweeper may only be operated by trained personnel! Special care is necessary when mounting / removing the scrubbing unit onto the vehicle. Possibility of injuries. When performing maintenance on the scrubbing unit, the vehicle ignition key...
Page 5: Mounting Scrubbing Unit
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Mounting Scrubbing Unit 1. Remove the sweeping unit from the front of the vehicle. See section 3.4.3 or 3.4.4 in original citymaster manual. 2. Remove the suction hood. See section 3.4.1 or 3.4.2 in original citymaster manual.
Page 6 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 5. Raise the attachment triangle completely and fix it in the raised position. Close the hydraulic throttle behind the driver's cab completely and open again in case of sweeping unit assembly (see Citymaster operating instructions, chapter 3.3.2).
Page 7 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 8. Connect the suction hoses on both sides, tighten all clamps on the suction hoses. 9. Mount the retaining clip on the right-hand longitudinal strut (behind the front wheel) and connect the dirt water hose to the hose at the scrubber.
Page 8 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 11. Connect hydraulics and water pipes as well as connectors for electrics and construction detection on the front. Lift Electric scrubber R brushes 2x freshwater leakoil Construction P brushes detection plug Load Sensing 12.
Page 9: Demounting Scrubbing Unit
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Demounting Scrubbing Unit 1. Insert the removal trolley left and right, secure and turn the locking screws downwards. Turn down when demounting Front 2. Open central screw. 3. Relieve all hydraulic couplings, therefore turn on the vehicle ignition and press all the adjusting movements shortly.
Page 10: Operation In Scrubbing Mode
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Operation in Scrubbing Mode Operation Panel Scrubbing Waterpump on/off brushes on speed waterpump Start scrubbing Start the operation of the machine in the same way as with mounted sweeping unit Lower the scrubbing unit by pressing the corresponding button. Raise the vehicle speed to the desired suction power (standard speed, fan speed approx.
Page 11 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 • Switch on the scrub brushes on the scrubber control panel. Note: The brush speed is set and should not be adjusted. If absolutely necessary, the speed can be adjusted by adjusting the line throttle.
Page 12 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Desired function and thus position of the 3-way ball valves see pictures. Position Position without freshwater chemical admixture Nozzle connector without chemical admixture *= special equipment . 12...
Page 13: Use Waste Water System
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Use waste water system Use waste water only if there has been enough waste water accumulated in the hopper, or pre-filled. Waste water can be used both with and without chemical admixture. • Switch vehicle into working mode (waste water valve opens) •...
Page 14: Chemistry Admixture
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Chemistry admixture* The admixture can be done with fresh water as well as dirty water operation. Insert chemical container and screw on dosing unit. Change the water hose to the nozzles. 2. Connect here Insert chemical container, 1.
Page 15: General Information
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 General Information Caution: The scrubbing brushes and suction hood must be lifted under all circumstances when driving over very uneven road surfaces and kerbstones! • Scrub brushes and suction unit can be raised and lowered separately. Because of this a individual brushing in detergent or sucking off without brushing is possible! •...
Page 16: Maintenance
Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Maintenance Attention! When performing maintenance on the scrubbing unit, the vehicle ignition key must be removed and kept in a safe place, inaccessible for other persons During maintenance or adjustment work, unauthorized commissioning must never be...
Page 17 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Cover strips Rear: over the entire range ground-touching • The sealing strip at the front of the suction hood has approx. 10 ... 15 mm ground clearance. Setting, as described, about the height of the trailing wheels.
Page 18 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 • The front sealing strips should be adjusted to approx. 1cm left and right and approx. 2cm ground clearance at the front. Ca.1cm Ca.2cm • Replace worn cleaning brushes. (Unit must be raised and secured against lowering by...
Page 19 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Linienf arben sind nich gleich Kabelf arben und dienen nur zur besseren Übersicht line colors are not the sam e cable colors- only f or better ov erv iew Steuerpult control board 07-623-4011...
Page 20 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 07-551-1003 0,8mm 0,8mm 0,8mm Grobgutklappe Bürstenantrieb ca.15...20 l/min brush driv e *= special equipment . 20...
Page 21 Trilety GmbH TSW2 Citymaster 2200 v1.03 01-2019 Chemie 07-521-0025 07-521-0025 Frischwasser Schmutzwasser f resh water waste water *= special equipment . 21...
Page 22: List Of Spare Parts
When ordering spare parts, to ensure that the correct spare parts are delivered, please always specify the machine type, construction year and serial number. These details are stamped on the TRILETY machine type plate that is fitted to the machine. *= special equipment...
