effiLine EFFI-LINE-V2 User Manual

Please take a while to consider and read this brochure before using your new device.
If you have any doubt, please refer to the datasheet on the website or contact EFFILUX.

User security

Do not look directly or with any optical instrument the light beam
•
Avoid any contact with the LED or with the projection lens
•
IP50 Classification: Do not immerse the device in water or any other liquids
•
Operating environment: 0 to 40°C - Humidity: 20 to 85RH% (without condensation)
•
High humidity and high temperature could damage the device
•
Do not use the device in an environment with oil fumes and steam
•
Do never try to fix any damages to the product by yourself
•
Make sure you are using a correct power supply before connecting the device
•
The device must be powered by a 24V safety power supply in accordance to local Electrical Safety rules
•
Do not inverse electrical polarity – check the conventions before turning on the power supply
•
Make sure you consider an adapted connector to link the device to the power supply
•
Mini Parc du Verger – Bâtiment E
1 Rue de Terre Neuve
91940 LES ULIS, FRANCE
High power LED linescan illumination system
Any improper use voids the warranty
Tel: +33 9 72 38 17 80
Fax: +33 9 72 11 21 69
Email: sales@effilux.fr
USER MANUAL EFFI-LINE-V2
Version 2.6.2022
Last update: February 23, 2022
UK Importer: Gardasoft Vision Ltd.
Trinity Court, Buckingway Business Park
Swavesey, Cambrige CB24 4UQ UK
Page 1 / 4
