DAKONTE DPGB 65 Series Assembly Instructions

Components Shipped

1. Clear Partition Screen with Sewn Edges and Hanging Straps
2. Plastic Base with Wheels
3. Qty (2) Upright Poles
4. Top Cross Bar Assembly with Extension Tubes on Each End

Tips

Use rubber mallet or heavy book to tap Upright Poles fully into the Plastic Base.
Be sure Velcro
Top Cross Bar Assembly are all facing the same side of the frame.
STEP 4:
STEP 2:
3" Long Hook Velcro® 5/8" Black
STEP 1:
Disclaimer: This partition is not intended to prevent specific diseases or
infections; provide a barrier to liquids; or provide protection from exposures or
injuries caused by physical impact, liquids, chemicals, high temperatures, dust or
debris. Individuals utilizing this partition are responsible for following all
applicable workplace regulatory requirements -including ADA accessibility.
EXCEPT WHERE SPECIFICALLY PROHIBITED BY LAW, NO WARRANTY IS PROVIDED
FOR THIS PARTITION'S FITNESS FOR A PARTICULAR PURPOSE.
Assembly Instructions

Floor Stand Partition Parts

®
Strips on lower part of black Upright Poles, and Velcro strip on
STEP 1:
STEP 1:
Insert Upright Poles into Plastic Base.
Push down firmly to ensure fully inserted.
Be sure Velcro® Strips on Upright Poles face
STEP 2:
same side of the frame assembly.
Extend silver inside poles to full upright
position. Lock in place.
STEP 2:
Place Top Cross Bar onto Upright Poles.
IMPORTANT – be sure Velcro® strips on Top
Cross Bar faces same side of frame as the
Velcro strips on the Upright Poles.
Push Cross Bar down firmly to fully insert.
Lift the locking tabs on the Top Cross Bar
and slide extension tubes outward to the
line marked on the tube. Relock in place.
STEP 3:
Tip sideways to insert wheels into the base
Insert wheels with locking tabs on same side.
STEP 4:
Unroll and drape the Clear Partition Screen
over the frame, loop straps over extension
bars to hold in place. Press onto Velcro®
strips to secure in place.
6615 W MILL ROAD, MILWAUKEE WISCONSIN 53218
For Assembly Assistance or Questions
Phone 800-238-3957
Email
COPYRIGHT 2020 DAKONTE Product GROUP, INC
DAKONTE PRODUCT GROUP, INC
dhill@dpgproducts.com
DPGIP-37-14 Rev 5
