High Road Wag'nRide Dog Barrier Frame Assembly

Pieces included:
2 - long "J" shaped rods with foam pad bumpers (A)
2 - short "J shaped rods with foam pad bumpers (B)
4 - webbed straps with buckles
1 - mesh barrier panel with side hook and loop
channels and bottom cord attachment

To assemble:

1. While pressing the spring lock down, insert straight end of rod A into curved end of rod B
until the lock clicks in place.
2. Repeat with remaining rods to form a rectangle (see diagram below).
3. Lightly pull on the rectangular frame to ensure rods are secure.
4. Lay the mesh panel flat with hook and loop side channels facing up.
5. Open the hook and loop channels, and place the metal frame so that the foam pads
are centered within.
6. Wrap the mesh channels around the foam pads and secure with the hook and look closures.
7. Buckle the webbed straps through all 4 corners of the frame.
B
A

Dog Barrier Frame Assembly

A
2 x
A
B
2 x B
