RAILBLAZA C-TUG SANDTRAKZ Quick Start Manual

CROSSBEAM

KICKSTAND

Slip the bottom of the kickstand into the
inside of one of the crossbeams.
Compress both sides of the crossbeam and
you should feel a click as the cross beam pins
fit into the opposite side.
Slip the wheel over the axle.
1
Pull kickstand completely through and ensure the
pins in the kick stand base insert into the indentions
on the inside of the Crossbeam.
4

HULL PAD

Swivel the hull pad into the hook.
7
Push down on axle pin till it clicks into the lock position.
2
Bring the other side of the crossbeam to
meet up against the kickstand side.
5
Continue to swivel the hull pad until it is flat.
The hull pads will pivot to fit your kayak hull.
8
CLICK TO
LOCK
Install straps as shown on back of instructions and
you are ready to use your C-TUG.
3
6
9
