EvolvePlus Pty Ltd
© 2016 EvolvePlus Pty Ltd
This publication is provided "as is" without warranty of any kind, either express or implied. The names of actual companies and products
mentioned herein may be the trademarks of their respective owners. We reserve the right to revise and make changes to the content of
this document from time to time without notice.
LCD Screen People Counter
Installation Guide &
Operating Instructions
Models: PRx20D1 - PTx20-1
PRx10D1 - PTx10-1
Version Date: March 2016
www.evolveplus.com.au
Advertisement
Table of Contents
Summary of Contents for EvolvePlus PRx20D1
- Page 1 EvolvePlus Pty Ltd LCD Screen People Counter Installation Guide & Operating Instructions Models: PRx20D1 - PTx20-1 PRx10D1 - PTx10-1 Version Date: March 2016 © 2016 EvolvePlus Pty Ltd www.evolveplus.com.au This publication is provided "as is" without warranty of any kind, either express or implied. The names of actual companies and products mentioned herein may be the trademarks of their respective owners.
- Page 2 Additional information ............................ 4 Check Alignment ............................... 5 Start Counting ..............................5 Resetting the count value ..........................5 Determine the direction of the count value (PRx20D1 & PTx20-1) ............... 5 IP54 Rated Outdoor Casing ..........................6 © 2016 EvolvePlus Pty Ltd www.evolveplus.com.au...
- Page 3 LCD Screen People Counter - Installation and Operation Guide Overview – PRx20D1 – PTx20-1(Bi-directional) The PRx20D1 - PTx20-1 (LCD screen display model) is a bi-directional people counter. The principle is based on the interruption of a horizontal infrared beam. The transmitter PTx20-1 transmits the infrared beam to the receiver "PRx20D1". When this infrared beam is interrupted, e.g.
- Page 4 When the transmitter counter (PTx20-1 or PTx10-1) is powered correctly the red LED in the circuit board will flash. When the receiver counter (PRx20D1 or PRx10D1) is powered correctly the LCD display screen will show ‘0’. Install People Counters When mounting the People Counters take care of the following: §...
- Page 5 The green status led on the receiver will blink once each time a count is created. Resetting the count value To reset the value on the display to 0, slide the magnet over the top side of the receiver (PRx20D1 or PRx10D1).
- Page 6 The LED Screen Display People Counters models are available with an optional Outdoor Casing which provides protection and durability for prolonged outdoor use. An optional metal bracket can be used to assist with mounting (not included with the standard IP54 Casing) © 2016 EvolvePlus Pty Ltd www.evolveplus.com.au...
