CTE TECH 8198 Instructions Manual

8198 instruction of meter
Product name：Meter (w
ith Bluetooth function)
Brand：CTE TECH CORP.
Model： 8198
1. Product explanation：
Vehicle device for large-sized motorcycle and provides a status of vehicle.
This meter can display such as vehicle speed, fuel quantity, total mileage, short
mileage, battery voltage, indicator light, time, gear position, remaining mileage,
average speed, average fuel efficiency, time functions, and also provides users with
the operation of the meter buttons to set the suitable interface for the users.
Meter button operation:
L can switch mileage mode: Change the mileage mode ODO＞＞TRIP A＞＞
TRIP B＞＞ODO
R can switch driving status: instantaneous fuel consumption->>average fuel
consumption>>remaining mileage>>average
voltage--instant fuel consumption
speed>>walking time-->battery
2. Specification：
System specification
Description
Size of main body
Wired connection interface
Wireless connection interface
APP
Outer case material
Weight
Operating Voltage
Operating Current
Quiescent Current (Key OFF)
Operating temperature
Storage temperature
Random Access Memory
Content
158.5*103.4*54mm
20pin connection interface
Bluetooth (BLE5.0)
Rideology
AES+PMMA
305g
DC 9V~16V +/-0.5V
150mA~500mA
0.8mA
-20~70℃
-30~80℃
4MB
