AXZON RFM5209 User Manual

Data hub with readerservice
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RFM5209 Data Hub
System
Software
APPLICATIONS
IoT sensing
Building performance
Factory 4.0 monitoring
Data center monitoring
Cold chain shipping
KEY FEATURES
Read temperature sensors
Wi-Fi hotspot visualizations
RJ45 Ethernet
Smart Passive Sensing™
Java-based Software
Aggregates RFM5108/9
108 x 119 x 45 mm
User Guide: RFM5209-B Data Hub with ReaderService
www.Axzon.com
Data Hub with ReaderService
What's in the system?
The RFM5209 is a data hub designed to aggregate data from
selected Axzon RF reader systems to access battery-free Smart
Passive Sensing™ devices. The RFM5209 includes the Java-based
ReaderService™ sensor management software with optimized sen-
sor reading algorithms. The RFM5209 is preconfigured as a Wi-Fi
hot spot to allow access to graphical data plots to monitor tem-
perature.
How is it used?
The RFM5209 system is connected to one or more separate RF
reader(s) over the network. The RF reader(s) will send data to
the RFM5209 data hub for storage in the internal database. This
sensor data is also available on your own smart phone or tablet
device when connected to the data hub's Wi-Fi.
RF Readers and Sensors sold separately
The RFM5209 system does not include the RF reader or sensors.
The RFM5108 or the RFM5109 RF readers are purchased separately.
Part numbers
The RFM5209-B is a system-level product that includes the
RFM5144-B ReaderService™ interface software that manages read-
er and sensor interactions, while also provides advanced sensor
data processing algorithms.
Start processing at the edge
RF Readers and
Sensors are
sold separately
Fixed RF reader
v0.2.0
RFM5209 USER GUIDE
Antenna
Page 1
IN034F11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFM5209 and is the answer not in the manual?

Questions and answers

Summary of Contents for AXZON RFM5209

  • Page 1 Fixed RF reader System Software What’s in the system? The RFM5209 is a data hub designed to aggregate data from APPLICATIONS selected Axzon RF reader systems to access battery-free Smart IoT sensing Passive Sensing™ devices. The RFM5209 includes the Java-based ReaderService™...

  • Page 2: Table Of Contents

    7.1. Find available readers 7.2. Connect to the reader 7.3. Adjust the network settings 7.4. Load settings into the reader ReaderService Master Architecture Additional Resources 10. Quick Start Process Page 2 User Guide: RFM5209-B Data Hub with ReaderService IN034F11 www.Axzon.com...

  • Page 3: Introduction

    1. Introduction The RFM5209 Data Hub system aggregates sen- Power source: The reader ships with an external sor data from one or more RF readers over the power supply. The BF suffix designation in the network. The RFM5144 ReaderService software...

  • Page 4: Reader And Sensors Purchased Separately

    While no sensors are communicate with the sensors and retrieve their shipped with the Data Hub, the RFM3200, data. Software running on the RFM5209 Data RFM3250 wireless temperature sensors and the hub communicates with the RF reader over Eth- RFM2100 moisture sensor are commonly sup- ernet to monitor sensor data.

  • Page 5: Connecting And Operating The Data Hub

    The 3.6. Wait for the services to start RFM3200 flexible temperature sensors are de- Wait for the RFM5209 to boot. This should take signed for non-metallic surfaces. less than one minute. RFM3250 antenna orientation.

  • Page 6: Accessing Sensor Data Over Wi-Fi

    4. Accessing Sensor Data Over Wi-Fi Please follow the instructions in section 3 to Collected data is available as an export from the ensure the RFM5209 is properly set up as a Wi-Fi Grafana tool. Please select the desired chart, access point.

  • Page 7: Troubleshooting And Maintenance Guide

    The reader can become “disconnected” if for ex- ample the Ethernet cable between the RFM5209 and the RF reader is physically disconnected. The RF reader and RFM5209 are configured to au- tomatically reconnect. To manually “reconnect” the reader to the Axzon ReaderService, you can...

  • Page 8: Using The System

    NOTE: If readings from a sensor appear erratic swagger-ui.html. and the reported OCRSSI power at that sensor is above 18, then use of the power modulation algorithm is advised. Page 8 User Guide: RFM5209-B Data Hub with ReaderService IN034F11 www.Axzon.com...

  • Page 9: Updating The Reader Network Configuration

    7.3. Adjust the network settings OPTIONAL: If your RF reader was shipped along with the RFM5209 Data Hub, the RF reader has Click the orange and white Network Settings already been configured to work with the Data button on the left side of the screen. This will Hub.

  • Page 10: Readerservice Master Architecture

    The critical access details are shown below. NOTE: Axzon is committed to the further development and maintenance of the REST interface. While we provide access information around the database and queue, we have not committed to maintaining these data views on a go-forward basis.

  • Page 11: Additional Resources

    System Options: PB031 RFM5108-B Fixed RAIN/UHF Reader with RfmApi Product Brochure PB054 RFM5109-B Fixed RAIN/UHF Smart Reader with ReaderService Product Brochure PB058 RFM5209-B Data Hub with ReaderService Product Brochure Software Options: PB047 RFM5140-B RfmApi Product Brochure PB048 RFM5144-B ReaderService Product Brochure...

  • Page 12: Quick Start Process

    STEP 1: Connect the RF antenna Please follow the instructions in RF reader user guide. STEP 2: Connect RFM5209 to the RF reader using Ethernet Please follow the instructions in section 3.4. STEP 3: Position sensors in front of the RF antenna Data Hub Please follow the instructions in section 6.2.
