ACC-A19/27R-S-35G
QUICK INSTALLATION GUIDE
MATERIALS
2 hald
grids
1 3.5GHz
illuminator
TOOLS
Llave 8 mm
Llave 10 mm
1.
ENSAMBLAJE DE LAS MEDIAS REJILLAS
27 dBi ANTENNA
19 dBi ANTENNA
2.
MOUNTING THE L-FITTING
4 M6x30 screws (27 dBi)/
M5x30 (19 dBi) with nuts
and washers
M6x12 screws (27 dBi)/
M5x12 (19 dBi) with nuts
and washers *
X2 M6x30
27 dBi antenna
X2 M5x30
19 dBi antenna
1 L fitting
2 clamps
* 4 pcs. in 27 dBi antenna / 2 pcs. in 19 dBi antenna.
10
X4 M6x12
8
X2 M5x12
10
27 dBi antenna
8
19 dBi antenna
2 serrated
fittinf
1 RF cable
(not included)
