AXS-CPE, LNK-LU050-15
QUICK INSTALLATION GUIDE
MATERIALS
1 35, 70 o r100
Mbps CPE
TOOLS
8 mm wrench
Philips
screwdriver
1.
CONNECTING THE ETHERNET CABLE TO THE CPE
2.
MOUNTING THE CPE ON THE MAST WITHOUT LIFTING KIT (BASIC)
1 metal
flange
1 mounting kit
with elevator *
* Use Cat-5e or higher Ethernet cable,
suitable for outdoors.
External antenna
(CPE-RS)*
Cable for extrenal
antenna (CPE-RS)*
* Optional materials.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for albentia AXS-CPE
- Page 1 AXS-CPE, LNK-LU050-15 QUICK INSTALLATION GUIDE MATERIALS 1 metal External antenna flange (CPE-RS)* 1 mounting kit Cable for extrenal with elevator * antenna (CPE-RS)* 1 35, 70 o r100 Mbps CPE * Optional materials. TOOLS 8 mm wrench Philips screwdriver CONNECTING THE ETHERNET CABLE TO THE CPE * Use Cat-5e or higher Ethernet cable, suitable for outdoors.
- Page 2 MOUNTING THE CPE ON THE MAST WITH SWING HARDWARE (OPTIONAL) EXTERNAL ANTENNA CONNECTION FOR CPE-RS MODELS All Albentia Systems products are designed and manufactured in the European Union AXS-CPE, LNK-LU050-15 INSTALLATION GUIDE IMPORTANT NOTE Default system configuration: Albentia Systems declares that this equipment complies with the essential...
